1，Kalman滤波器参数如何选取

#!/usr/bin/env python
# -*- coding: UTF-8 -*-
'''=========================================================================================================
@Project -> File   ：active -> kalmanEstimateConstant
@IDE    ：PyCharm
@Author ：Mr. Ddc
@Date   ：2020/2/12 15:34
@Desc   ：对参考文献中的例子（估计一个常数）进行仿真，深入理解Kalman滤波器的参数对滤波性能的影响。
@Ref    ：Welch & Bishop, An Introduction to the Kalman Filter, UNC-Chapel Hill, TR 95-041, July 24, 2006
=========================================================================================================='''

import sys
import traceback
import getopt
import numpy as np
import matplotlib.pyplot as plt


# 模拟观测数据
def simData(xTruth, sigma, N):
    data = np.random.normal(xTruth, sigma, N)
    # np.savetxt("SimData.txt", data)  # 数据存盘
    return data

# 1维数据滤波
def filter1D(z, Q, R):
    x = np.zeros(z.shape)  # 滤波值
    pkk = np.zeros(z.shape)  # 滤波协方差
    dis = np.zeros(z.shape)  # 新息统计距离

    # 初始化
    x[0] = z[0]
    pkk[0] = R

    for i in range(1, z.size):
        xki = x[i-1]  # 状态的一步预测
        pki = pkk[i-1] + Q  # 协方差的一步预测
        v = z[i] - xki  # 新息
        S =  pki + R  # 新息的协方差
        K = pki / S  # 增益
        x[i] = xki + K * v  # 状态的更新
        # pkk[i] = pki - K*S*K  # 协方差的更新  # 两者是相同的
        pkk[i] = (1 - K) * pki  # 协方差的更新
        dis[i] = v / S * v  # 新息统计距离

    return x, pkk, dis

# 画图
def display(Q, R, xTruth, z, x, pkk, dis, ivSta):
    N = z.size

    # 颜色表
    colors = []
    colors.append('b')  # 参数1
    colors.append('g')  # 参数2
    colors.append('r')  # 参数3
    colors.append('y')  # 参数4
    colors.append('c')  # 参数5
    colors.append('m')  # 观测值用
    colors.append('orange')  # 真值用

    # markers
    markers = []
    markers.append('o')  # 参数1
    markers.append('v')  # 参数2
    markers.append('d')  # 参数3
    markers.append('x')  # 参数4
    markers.append('+')  # 参数5

    # 画 真值、观测值、滤波值
    title = '状态'
    plt.figure(title)
    plt.plot(np.arange(N) + 1, xTruth * np.ones(N), color = colors[len(colors)-1], label = '真值')  # plot
    plt.plot(np.arange(N) + 1, z, '.-', color = colors[len(colors)-2], label = '观测值')  # plot
    for i in range(0, len(R)):
        plt.plot(np.arange(N) + 1, x[i, :], 'o-',
                 marker = markers[i], color = colors[i], label = f'({i+1}):Q = {Q[i]: .6f}, R = {R[i]:.4f}')  # plot

    plt.legend()
    plt.xlabel('时间')  # 设置x轴标签
    plt.ylabel('电压')  # 设置y轴标签
    # plt.title(title)
    plt.savefig(title)

    # 画 滤波值的方差
    title = '滤波值的方差'
    fig = plt.figure(title)
    # 主图 ax1
    left, bottom, width, height = 0.15, 0.11, 0.8, 0.8
    ax1 = fig.add_axes([left, bottom, width, height])
    for i in range(0, len(R)):
        ax1.plot(np.arange(N)+1, pkk[i], '.-',
                 marker = markers[i], color = colors[i], label = f'({i+1}):Q = {Q[i]: .6f}, R = {R[i]:.4f}')  # plot

    ax1.legend(loc = 'upper right')
    ax1.grid()
    ax1.set_ylabel('方差')  # 设置y轴标签  斜体
    ax1.set_xlabel('时间')  # 设置x轴标签
    # ax1.set_ylabel('$\mathregular{Voltage^2}$')  # 设置y轴标签 去除斜体
    ax1.set_ylim([-0.002, 0.02])
    # ax1.set_title(title)
    # 子图，由于参数3对应的方差太大，用子图另画
    left, bottom, width, height = 0.25, 0.6, 0.25, 0.25
    ax2 = fig.add_axes([left, bottom, width, height])
    ax2.plot(np.arange(N)+1, pkk[3], '.-', marker = markers[3],  color = colors[3])
    ax2.grid()
    ax2.set_ylabel('方差', fontsize = 'small')  # 设置y轴标签
    ax2.set_xlabel('时间', fontsize = 'small')  # 设置x轴标签
    ax2.set_title('参数4', fontsize = 'small')
    ax2.patch.set_visible(False)  # 设置子图透明
    plt.savefig(title)

    # 画 新息的统计距离
    title = '新息的统计距离'
    fig = plt.figure(title)
    # 主图 ax1
    left, bottom, width, height = 0.12, 0.11, 0.8, 0.8
    ax1 = fig.add_axes([left, bottom, width, height])
    for i in range(0, len(R)):
        ax1.plot(np.arange(N)+1, dis[i, :], '.-',
                 marker = markers[i], color = colors[i], label = f'({i+1}):Q = {Q[i]: .6f}, R = {R[i]:.4f}')  # plot

    ax1.legend(loc = 'upper right')
    ax1.set_xlabel('时间')  # 设置x轴标签
    ax1.set_ylabel('统计距离')  # 设置y轴标签
    ax1.set_ylim([-0.1, 7])
    ax1.grid()
    # 子图，由于参数4对应的方差太大，用子图另画
    left, bottom, width, height = 0.23, 0.6, 0.25, 0.25
    ax2 = fig.add_axes([left, bottom, width, height])
    ax2.plot(np.arange(N)+1, dis[4], '.-', marker = markers[4], color = colors[4])
    ax2.set_xlabel('时间', fontsize = 'small')  # 设置x轴标签
    ax2.set_ylabel('统计距离', fontsize = 'small')  # 设置y轴标签
    ax2.grid()
    ax2.set_title('参数5', fontsize = 'small')
    ax2.patch.set_visible(False)  # 设置子图透明
    plt.savefig(title)

    # 画 新息的统计距离的统计信息
    txt = ('最小值', '最大值', '平均值', '标准差')
    title = '新息的统计距离的统计信息'
    fig = plt.figure(title)
    # 主图 ax1
    left, bottom, width, height = 0.12, 0.11, 0.8, 0.8
    ax1 = fig.add_axes([left, bottom, width, height])
    for i in range(0, ivSta.shape[1]):
        ax1.plot(np.arange(ivSta.shape[0])+1, ivSta[:, i], '.-', label = txt[i])  # plot

    ax1.legend(loc = 'upper right')
    ax1.set_xticks(np.arange(ivSta.shape[0])+1)
    ticks = []
    for i in range(ivSta.shape[0]):
        ticks.append('参数' + str(i+1))
    ax1.set_xticklabels(ticks)
    ax1.set_ylim([-0.3, 9])
    ax1.grid()
    # 子图，由于参数4对应的值太大，用子图另画
    left, bottom, width, height = 0.23, 0.6, 0.25, 0.25
    ax2 = fig.add_axes([left, bottom, width, height])
    ax2.bar(range(0, 3), ivSta[-1, 1:], alpha = 0.5)
    ax2.set_xticks(range(0, 3))
    ax2.set_xticklabels(txt[1:], rotation = 30, fontsize = 'small')
    ax2.patch.set_visible(False)  # 设置子图透明
    # for item in [fig, ax2]:  # 设置子图透明
    #     item.patch.set_visible(False)
    ax2.grid()
    ax2.set_title('参数5', fontsize = 'small')
    plt.savefig(title)

    plt.show()

# Works 实现主要功能
def Works():
    N = 100  # 观测次数
    xTruth = -0.37727  # 真值
    sigma = 0.1  # 叠加正态分布噪声的标准差
    r = sigma ** 2  # 观测方差

    # 1，模拟一次数据
    # simData(xTruth, sigma, N)  # 模拟观测数据
    # z = np.loadtxt("SimData.txt")  # 从硬盘读取数据
    z = simData(xTruth, sigma, N)  # 模拟观测数据

    plt.figure("模拟数据直方图统计")
    count, bins, ignored = plt.hist(z, z.size)
    plt.plot(bins, 1 / (sigma * np.sqrt(2 * np.pi)) * np.exp( - (bins - xTruth)**2 / (2 * sigma**2) ), linewidth = 2, color = 'r')
    plt.savefig("模拟数据直方图统计")

    # 五组参数
    R = [r,     r,      r,      r*100,  r/100]
    Q = [1e-5,  r/9,    2*r,    1e-5,   1e-5]
    x = np.zeros((len(R), z.size))  # 滤波值，各行依次对应一组参数
    pkk = np.zeros((len(R), z.size))  # 滤波协方差，各行依次对应一组参数
    dis = np.zeros((len(R), z.size))  # 新息统计距离，各行依次对应一组参数

    for idxR in range(0, len(R)):
        r = R[idxR]
        q = Q[idxR]
        x[idxR, :], pkk[idxR, :], dis[idxR, :] = filter1D(z, q, r)  # 滤波

    # 统计新息的最小值/最大值/平均值/标准差
    ivSta = np.zeros((len(R), 4))  # 各行依次对应一组参数
    for idxR in range(0, len(R)):
        ivSta[idxR, :] = (np.min(dis[idxR, :]), np.max(dis[idxR, :]), np.mean(dis[idxR, :]), np.std(dis[idxR, :], ddof = 1) )

    display(Q, R, xTruth, z, x, pkk, dis, ivSta)  # 画图

    return 0


# 异常处理函数
class Usage(Exception):
    def __init__(self, msg):
        self.msg = msg


# main()函数
def main(argv=None):
    if argv is None:
        argv = sys.argv
    try:
        try:
            opts, args = getopt.getopt(argv[1:], "h", ["help"])
        except(getopt.error, msg):
            raise (Usage(msg))

        # 使plt支持中文
        plt.rcParams['font.sans-serif'] = ['SimHei']
        plt.rcParams['axes.unicode_minus'] = False

        # Works 实现主要功能
        Works()
    except Usage as err:  # 待处理新增代码中的异常
        print(sys.stderr, err.msg)
        print(sys.stderr, "for help use --help")
        return 1
    except Exception as e:
        print("print_exception()")
        exc_type, exc_value, exc_tb = sys.exc_info()
        print('the exc type is:', exc_type)
        print('the exc value is:', exc_value)
        print('the exc tb is:', exc_tb)
        traceback.print_exception(exc_type, exc_value, exc_tb)
    finally:
        print('exit main')


# 直接运行的入口
if "__main__" == __name__:
    sys.exit(main())
