[数据分析]模型可解释性：你的机器学习模型不再是黑盒

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
from sklearn.model_selection import train_test_split
from sklearn.ensemble import RandomForestClassifier, GradientBoostingClassifier
from sklearn.linear_model import LogisticRegression
from sklearn.metrics import accuracy_score, classification_report, confusion_matrix
import warnings
warnings.filterwarnings('ignore')

# 设置中文字体
plt.rcParams['font.sans-serif'] = ['SimHei']
plt.rcParams['axes.unicode_minus'] = False

print("环境设置完成，开始模型可解释性探索...")

class InterpretableBaseModels:
    """可解释基础模型类"""

    def __init__(self):
        self.models = {}
        self.explanations = {}

    def create_credit_risk_dataset(self, n_samples=10000):
        """创建信用风险评估数据集"""
        np.random.seed(42)

        # 生成相对真实的信用数据
        data = {
            'age': np.random.normal(45, 15, n_samples),
            'income': np.random.lognormal(11, 0.5, n_samples),  # 年收入
            'credit_score': np.random.normal(700, 100, n_samples),
            'debt_to_income': np.random.beta(2, 5, n_samples) * 100,  # 债务收入比
            'years_employed': np.random.exponential(10, n_samples),
            'loan_amount': np.random.gamma(2, 10000, n_samples),
            'savings_balance': np.random.exponential(50000, n_samples),
            'existing_loans': np.random.poisson(2, n_samples),
            'education_level': np.random.choice(['高中', '本科', '硕士', '博士'],
                                              n_samples, p=[0.3, 0.4, 0.2, 0.1]),
            'home_ownership': np.random.choice(['租房', '有房贷', '全款房'],
                                             n_samples, p=[0.4, 0.4, 0.2])
        }

        df = pd.DataFrame(data)

        # 基于业务逻辑生成违约标签
        # 违约概率与多个因素相关
        default_prob = (
            0.1 +
            0.3 * (df['debt_to_income'] > 40) +
            0.2 * (df['credit_score'] < 600) +
            0.15 * (df['loan_amount'] > df['income'] * 0.5) +
            0.1 * (df['years_employed'] < 2) -
            0.1 * (df['education_level'].isin(['硕士', '博士'])) -
            0.05 * (df['home_ownership'] == '全款房') +
            np.random.normal(0, 0.1, n_samples)
        )

        df['default'] = (default_prob > 0.5).astype(int)

        return df

    def prepare_features(self, df):
        """特征预处理"""
        df_processed = df.copy()

        # 数值特征标准化
        numerical_features = ['age', 'income', 'credit_score', 'debt_to_income',
                            'years_employed', 'loan_amount', 'savings_balance', 'existing_loans']

        from sklearn.preprocessing import StandardScaler
        scaler = StandardScaler()
        df_processed[numerical_features] = scaler.fit_transform(df_processed[numerical_features])

        # 类别特征编码
        df_processed = pd.get_dummies(df_processed, columns=['education_level', 'home_ownership'])

        return df_processed, numerical_features

    def train_interpretable_models(self, X, y):
        """训练可解释模型"""
        # 划分训练测试集
        X_train, X_test, y_train, y_test = train_test_split(
            X, y, test_size=0.3, random_state=42, stratify=y
        )

        # 1. 逻辑回归（高可解释性）
        lr_model = LogisticRegression(max_iter=1000, random_state=42)
        lr_model.fit(X_train, y_train)

        # 2. 决策树（中等可解释性）
        from sklearn.tree import DecisionTreeClassifier, export_text
        dt_model = DecisionTreeClassifier(max_depth=5, random_state=42)
        dt_model.fit(X_train, y_train)

        # 3. 线性判别分析
        from sklearn.discriminant_analysis import LinearDiscriminantAnalysis
        lda_model = LinearDiscriminantAnalysis()
        lda_model.fit(X_train, y_train)

        self.models = {
            'Logistic Regression': lr_model,
            'Decision Tree': dt_model,
            'LDA': lda_model
        }

        # 模型性能评估
        performance = {}
        for name, model in self.models.items():
            y_pred = model.predict(X_test)
            accuracy = accuracy_score(y_test, y_pred)
            performance[name] = accuracy

        return X_train, X_test, y_train, y_test, performance

    def explain_linear_model(self, model, feature_names, X_train):
        """解释线性模型"""
        explanations = {}

        # 系数分析
        if hasattr(model, 'coef_'):
            coefficients = model.coef_[0]
            feature_importance = pd.DataFrame({
                'feature': feature_names,
                'coefficient': coefficients,
                'abs_coefficient': abs(coefficients)
            }).sort_values('abs_coefficient', ascending=False)

            explanations['coefficients'] = feature_importance

            # 特征重要性可视化
            plt.figure(figsize=(10, 6))
            top_features = feature_importance.head(10)
            colors = ['red' if x < 0 else 'green' for x in top_features['coefficient']]
            plt.barh(top_features['feature'], top_features['coefficient'], color=colors)
            plt.xlabel('系数大小')
            plt.title('逻辑回归特征系数（红色负向，绿色正向）')
            plt.tight_layout()
            plt.show()

        # 概率解释
        if hasattr(model, 'predict_proba'):
            # 显示基准概率
            baseline_prob = model.predict_proba(X_train[:1])[0][1]
            explanations['baseline_probability'] = baseline_prob

            print(f"基准违约概率: {baseline_prob:.3f}")

        return explanations

    def explain_decision_tree(self, model, feature_names):
        """解释决策树模型"""
        from sklearn.tree import plot_tree

        explanations = {}

        # 树结构可视化
        plt.figure(figsize=(20, 10))
        plot_tree(model,
                 feature_names=feature_names,
                 class_names=['正常', '违约'],
                 filled=True,
                 rounded=True,
                 fontsize=10)
        plt.title('决策树结构可视化')
        plt.show()

        # 特征重要性
        if hasattr(model, 'feature_importances_'):
            importance_df = pd.DataFrame({
                'feature': feature_names,
                'importance': model.feature_importances_
            }).sort_values('importance', ascending=False)

            explanations['feature_importance'] = importance_df

            # 可视化特征重要性
            plt.figure(figsize=(10, 6))
            plt.barh(importance_df['feature'][:10], importance_df['importance'][:10])
            plt.xlabel('特征重要性')
            plt.title('决策树特征重要性排名')
            plt.tight_layout()
            plt.show()

        # 提取决策规则
        from sklearn.tree import export_text
        tree_rules = export_text(model, feature_names=feature_names)
        explanations['decision_rules'] = tree_rules

        print("决策树规则示例:")
        print(tree_rules[:1000])  # 显示前1000字符

        return explanations

# 使用可解释基础模型
interpreter = InterpretableBaseModels()
credit_data = interpreter.create_credit_risk_dataset(5000)
processed_data, num_features = interpreter.prepare_features(credit_data)

# 准备特征和目标
X = processed_data.drop('default', axis=1)
y = processed_data['default']
feature_names = X.columns.tolist()

# 训练模型
X_train, X_test, y_train, y_test, performance = interpreter.train_interpretable_models(X, y)

print("模型性能比较:")
for model, acc in performance.items():
    print(f"{model}: 准确率 = {acc:.3f}")

# 解释逻辑回归模型
lr_explanations = interpreter.explain_linear_model(
    interpreter.models['Logistic Regression'], feature_names, X_train
)

print("\n逻辑回归关键发现:")
print("正向影响特征（增加违约概率）:")
positive_effects = lr_explanations['coefficients'][lr_explanations['coefficients']['coefficient'] > 0]
print(positive_effects[['feature', 'coefficient']].head())

print("\n负向影响特征（降低违约概率）:")
negative_effects = lr_explanations['coefficients'][lr_explanations['coefficients']['coefficient'] < 0]
print(negative_effects[['feature', 'coefficient']].head())

# 解释决策树模型
dt_explanations = interpreter.explain_decision_tree(
    interpreter.models['Decision Tree'], feature_names
)

class SHAPExplainer:
    """SHAP值解释器"""

    def __init__(self):
        self.shap_values = {}
        self.explainers = {}

    def comprehensive_shap_analysis(self, model, X, y, model_name='model'):
        """全面的SHAP分析"""
        try:
            import shap
        except ImportError:
            print("请先安装SHAP库: pip install shap")
            return None

        # 创建解释器
        if hasattr(model, 'predict_proba'):
            explainer = shap.TreeExplainer(model) if hasattr(model, 'estimators_') else shap.Explainer(model, X)
            shap_values = explainer(X)
        else:
            explainer = shap.Explainer(model, X)
            shap_values = explainer(X)

        self.explainers[model_name] = explainer
        self.shap_values[model_name] = shap_values

        # 创建综合可视化
        self._create_shap_visualizations(shap_values, X, y, model_name)

        return explainer, shap_values

    def _create_shap_visualizations(self, shap_values, X, y, model_name):
        """创建SHAP可视化"""
        import shap

        print(f"\n=== {model_name} SHAP分析结果 ===\n")

        # 1. 特征重要性总结图
        plt.figure(figsize=(10, 8))
        shap.summary_plot(shap_values, X, show=False)
        plt.title(f'{model_name} - SHAP特征重要性总结')
        plt.tight_layout()
        plt.show()

        # 2. 特征重要性条形图
        plt.figure(figsize=(10, 6))
        shap.summary_plot(shap_values, X, plot_type="bar", show=False)
        plt.title(f'{model_name} - 平均SHAP绝对值重要性')
        plt.tight_layout()
        plt.show()

        # 3. 依赖图（对最重要特征）
        feature_names = X.columns
        if hasattr(shap_values, 'values'):
            mean_shap = np.abs(shap_values.values).mean(0)
        else:
            mean_shap = np.abs(shap_values).mean(0)

        top_feature_idx = np.argmax(mean_shap)
        top_feature = feature_names[top_feature_idx]

        plt.figure(figsize=(12, 6))
        shap.dependence_plot(top_feature_idx, shap_values.values if hasattr(shap_values, 'values') else shap_values,
                           X, display_features=X, show=False)
        plt.title(f'{model_name} - {top_feature}的SHAP依赖图')
        plt.tight_layout()
        plt.show()

        # 4. 个体预测解释
        self._explain_individual_predictions(shap_values, X, y, model_name)

    def _explain_individual_predictions(self, shap_values, X, y, model_name):
        """解释个体预测"""
        import shap

        # 选择几个有代表性的样本进行解释
        n_samples = min(3, len(X))

        # 找到预测概率接近0.5的边界案例
        if hasattr(shap_values, 'values'):
            predicted_proba = shap_values.values[:, 1] if shap_values.values.shape[1] > 1 else shap_values.values[:, 0]
        else:
            predicted_proba = shap_values[:, 1] if shap_values.shape[1] > 1 else shap_values[:, 0]

        borderline_indices = np.argsort(np.abs(predicted_proba - 0.5))[:n_samples]

        for i, idx in enumerate(borderline_indices):
            print(f"\n--- 样本 {i+1} 个体解释 (索引: {idx}) ---")
            print(f"真实标签: {y.iloc[idx]}, 预测概率: {predicted_proba[idx]:.3f}")

            # 创建力力图
            plt.figure(figsize=(12, 4))
            shap.waterfall_plot(shap_values[idx], show=False)
            plt.title(f'{model_name} - 样本 {idx} 预测解释')
            plt.tight_layout()
            plt.show()

            # 显示特征值
            sample_features = X.iloc[idx]
            print("特征值:")
            for feature, value in sample_features.items():
                print(f"  {feature}: {value:.3f}")

    def compare_models_shap(self, models_dict, X, y):
        """比较多个模型的SHAP解释"""
        import shap

        comparison_results = {}

        for name, model in models_dict.items():
            print(f"\n正在分析 {name}...")
            explainer, shap_vals = self.comprehensive_shap_analysis(model, X, y, name)
            comparison_results[name] = {
                'explainer': explainer,
                'shap_values': shap_vals
            }

        # 比较特征重要性
        self._compare_feature_importance(comparison_results, X.columns)

        return comparison_results

    def _compare_feature_importance(self, comparison_results, feature_names):
        """比较不同模型的特征重要性"""
        importance_comparison = {}

        for model_name, results in comparison_results.items():
            shap_vals = results['shap_values']

            if hasattr(shap_vals, 'values'):
                mean_abs_shap = np.abs(shap_vals.values).mean(0)
            else:
                mean_abs_shap = np.abs(shap_vals).mean(0)

            importance_df = pd.DataFrame({
                'feature': feature_names,
                'importance': mean_abs_shap
            }).sort_values('importance', ascending=False)

            importance_comparison[model_name] = importance_df

        # 创建比较可视化
        fig, axes = plt.subplots(2, 2, figsize=(15, 12))

        models = list(importance_comparison.keys())
        for i, model in enumerate(models):
            ax = axes[i//2, i%2]
            top_features = importance_comparison[model].head(10)
            ax.barh(top_features['feature'], top_features['importance'])
            ax.set_title(f'{model} - Top 10特征重要性')
            ax.set_xlabel('平均|SHAP值|')

        plt.tight_layout()
        plt.show()

        # 输出一致性分析
        self._analyze_importance_consistency(importance_comparison)

    def _analyze_importance_consistency(self, importance_comparison):
        """分析特征重要性的一致性"""
        # 提取每个模型的前10重要特征
        top_features_by_model = {}
        for model, importance_df in importance_comparison.items():
            top_features = importance_df.head(10)['feature'].tolist()
            top_features_by_model[model] = set(top_features)

        # 计算模型间的一致性
        models = list(top_features_by_model.keys())
        consistency_matrix = pd.DataFrame(index=models, columns=models)

        for i, model1 in enumerate(models):
            for j, model2 in enumerate(models):
                if i == j:
                    consistency_matrix.loc[model1, model2] = 1.0
                else:
                    set1 = top_features_by_model[model1]
                    set2 = top_features_by_model[model2]
                    overlap = len(set1.intersection(set2))
                    consistency = overlap / min(len(set1), len(set2))
                    consistency_matrix.loc[model1, model2] = consistency

        print("\n模型间特征重要性一致性矩阵:")
        print(consistency_matrix)

# 训练一个黑盒模型进行比较
from sklearn.ensemble import RandomForestClassifier

rf_model = RandomForestClassifier(n_estimators=100, random_state=42)
rf_model.fit(X_train, y_train)

# 添加到模型字典
all_models = {
    'Logistic Regression': interpreter.models['Logistic Regression'],
    'Decision Tree': interpreter.models['Decision Tree'],
    'Random Forest': rf_model
}

# 进行SHAP分析
shap_explainer = SHAPExplainer()
shap_comparison = shap_explainer.compare_models_shap(all_models, X_test, y_test)

class LIMEExplainer:
    """LIME解释器"""

    def __init__(self):
        self.explanations = {}

    def lime_local_explanations(self, model, X, y, feature_names, class_names=None):
        """LIME局部解释"""
        try:
            import lime
            import lime.lime_tabular
        except ImportError:
            print("请先安装LIME库: pip install lime")
            return None

        if class_names is None:
            class_names = ['正常', '违约']

        # 创建LIME解释器
        explainer = lime.lime_tabular.LimeTabularExplainer(
            X.values,
            feature_names=feature_names,
            class_names=class_names,
            mode='classification',
            random_state=42
        )

        # 选择几个有代表性的样本
        representative_indices = self._select_representative_samples(model, X, y)

        explanations = {}
        for idx in representative_indices:
            print(f"\n=== 样本 {idx} 的LIME解释 ===")
            explanation = self._explain_single_instance(
                explainer, model, X.iloc[idx], y.iloc[idx], idx
            )
            explanations[idx] = explanation

        self.explanations = explanations
        return explainer, explanations

    def _select_representative_samples(self, model, X, y):
        """选择有代表性的样本"""
        # 获取预测概率
        if hasattr(model, 'predict_proba'):
            y_pred_proba = model.predict_proba(X)[:, 1]
        else:
            y_pred_proba = model.predict(X)

        # 选择不同类型的样本
        indices = []

        # 1. 高置信度正确预测
        correct_predictions = (y_pred_proba > 0.7) & (y == 1) | (y_pred_proba < 0.3) & (y == 0)
        if correct_predictions.any():
            indices.append(correct_predictions.idxmax())

        # 2. 边界案例（预测概率接近0.5）
        borderline = np.abs(y_pred_proba - 0.5) < 0.1
        if borderline.any():
            indices.append(borderline.idxmax())

        # 3. 错误预测
        y_pred = (y_pred_proba > 0.5).astype(int)
        wrong_predictions = y_pred != y
        if wrong_predictions.any():
            indices.append(wrong_predictions.idxmax())

        return indices[:3]  # 最多返回3个样本

    def _explain_single_instance(self, explainer, model, instance, true_label, idx):
        """解释单个实例"""
        import lime

        # 生成解释
        explanation = explainer.explain_instance(
            instance.values,
            model.predict_proba if hasattr(model, 'predict_proba') else lambda x: np.column_stack([1-model.predict(x), model.predict(x)]),
            num_features=10
        )

        # 显示解释结果
        print(f"真实标签: {true_label}")

        # 显示预测概率
        if hasattr(model, 'predict_proba'):
            proba = model.predict_proba(instance.values.reshape(1, -1))[0]
            print(f"预测概率: 正常={proba[0]:.3f}, 违约={proba[1]:.3f}")

        # 显示特征贡献
        print("\n特征贡献（正向增加违约概率，负向降低违约概率）:")
        for feature, weight in explanation.as_list():
            print(f"  {feature}: {weight:.4f}")

        # 可视化解释
        fig = explanation.as_pyplot_figure()
        plt.title(f'样本 {idx} 的LIME解释')
        plt.tight_layout()
        plt.show()

        return explanation

# 使用LIME解释器
lime_explainer = LIMEExplainer()
lime_results = lime_explainer.lime_local_explanations(
    rf_model, X_test, y_test, feature_names
)

class AdvancedModelExplainer:
    """高级模型解释器"""

    def __init__(self):
        self.analysis_results = {}

    def partial_dependence_analysis(self, model, X, y, feature_names, top_features=5):
        """部分依赖分析"""
        from sklearn.inspection import PartialDependenceDisplay

        # 选择最重要的特征
        if hasattr(model, 'feature_importances_'):
            importance_scores = model.feature_importances_
        else:
            # 使用 permutation importance
            from sklearn.inspection import permutation_importance
            perm_importance = permutation_importance(model, X, y, n_repeats=10, random_state=42)
            importance_scores = perm_importance.importances_mean

        top_indices = np.argsort(importance_scores)[-top_features:][::-1]
        top_feature_names = [feature_names[i] for i in top_indices]

        print(f"分析前 {top_features} 个最重要特征的部分依赖:")
        print(top_feature_names)

        # 创建PDP图
        fig, ax = plt.subplots(figsize=(15, 10))
        PartialDependenceDisplay.from_estimator(
            model, X, features=top_indices,
            feature_names=feature_names,
            ax=ax
        )
        plt.suptitle('部分依赖图 (PDP) - 显示特征对预测的平均影响')
        plt.tight_layout()
        plt.show()

        # 创建ICE图
        self._individual_conditional_expectation(model, X, top_indices, feature_names)

        return top_feature_names

    def _individual_conditional_expectation(self, model, X, feature_indices, feature_names):
        """个体条件期望图"""
        from sklearn.inspection import PartialDependenceDisplay

        fig, axes = plt.subplots(2, min(3, len(feature_indices)), figsize=(15, 8))
        axes = axes.flatten()

        for i, feature_idx in enumerate(feature_indices[:len(axes)]):
            PartialDependenceDisplay.from_estimator(
                model, X, features=[feature_idx],
                feature_names=feature_names,
                kind='individual',
                ax=axes[i]
            )
            axes[i].set_title(f'{feature_names[feature_idx]} - ICE图')

        plt.suptitle('个体条件期望 (ICE) - 显示个体预测的变化')
        plt.tight_layout()
        plt.show()

    def feature_interaction_analysis(self, model, X, feature_names):
        """特征交互作用分析"""
        try:
            from sklearn.inspection import PartialDependenceDisplay

            # 选择两个最重要的特征分析交互
            if hasattr(model, 'feature_importances_'):
                importance_scores = model.feature_importances_
            else:
                importance_scores = np.abs(model.coef_[0]) if hasattr(model, 'coef_') else np.ones(X.shape[1])

            top_indices = np.argsort(importance_scores)[-2:][::-1]

            # 创建交互图
            fig, ax = plt.subplots(figsize=(10, 8))
            PartialDependenceDisplay.from_estimator(
                model, X, features=[(top_indices[0], top_indices[1])],
                feature_names=feature_names,
                ax=ax
            )
            plt.title('特征交互图 - 显示两个特征的联合影响')
            plt.tight_layout()
            plt.show()

            print(f"分析特征交互: {feature_names[top_indices[0]]} 和 {feature_names[top_indices[1]]}")

        except Exception as e:
            print(f"交互分析失败: {e}")

    def counterfactual_explanations(self, model, X, y, feature_names, instance_idx=0):
        """反事实解释"""
        print(f"\n=== 反事实解释分析 ===\n")

        # 选择要解释的实例
        instance = X.iloc[instance_idx:instance_idx+1]
        true_label = y.iloc[instance_idx]

        if hasattr(model, 'predict_proba'):
            original_prediction = model.predict_proba(instance)[0][1]
        else:
            original_prediction = model.predict(instance)[0]

        print(f"实例 {instance_idx} 的原始情况:")
        print(f"真实标签: {true_label}, 预测违约概率: {original_prediction:.3f}")

        # 生成反事实解释
        counterfactuals = self._generate_counterfactuals(model, instance, feature_names, target_prob=0.3)

        return counterfactuals

    def _generate_counterfactuals(self, model, instance, feature_names, target_prob=0.3):
        """生成反事实解释"""
        import copy

        instance_copy = copy.deepcopy(instance.values[0])
        original_features = instance_copy.copy()

        # 简单的反事实生成策略
        feature_changes = []
        current_prob = model.predict_proba(instance)[0][1]

        print(f"\n当前违约概率: {current_prob:.3f}")
        print(f"目标违约概率: {target_prob:.3f}")
        print("\n如何降低违约概率:")

        # 尝试调整每个特征
        for i, (feature, original_value) in enumerate(zip(feature_names, original_features)):
            if current_prob <= target_prob:
                break

            # 创建修改后的实例
            modified_instance = original_features.copy()

            # 根据特征类型进行合理修改
            if 'debt' in feature.lower() or 'loan' in feature.lower():
                # 债务相关特征：降低值
                modified_value = original_value * 0.7  # 降低30%
            elif 'income' in feature.lower() or 'savings' in feature.lower() or 'credit' in feature.lower():
                # 收入、储蓄、信用相关：增加值
                modified_value = original_value * 1.3  # 增加30%
            else:
                # 其他特征：轻微调整
                modified_value = original_value * 1.1

            modified_instance[i] = modified_value
            new_prob = model.predict_proba(modified_instance.reshape(1, -1))[0][1]

            if new_prob < current_prob:  # 如果修改降低了违约概率
                change_percent = (modified_value - original_value) / original_value * 100
                prob_change = (new_prob - current_prob) / current_prob * 100

                print(f"  • {feature}: {original_value:.2f} → {modified_value:.2f} ({change_percent:+.1f}%)")
                print(f"    违约概率: {current_prob:.3f} → {new_prob:.3f} ({prob_change:+.1f}%)")

                feature_changes.append({
                    'feature': feature,
                    'original': original_value,
                    'modified': modified_value,
                    'change_percent': change_percent,
                    'old_prob': current_prob,
                    'new_prob': new_prob,
                    'prob_change': prob_change
                })

                # 更新当前概率
                current_prob = new_prob

        return feature_changes

# 使用高级解释技术
advanced_explainer = AdvancedModelExplainer()

# 部分依赖分析
important_features = advanced_explainer.partial_dependence_analysis(
    rf_model, X_test, y_test, feature_names
)

# 特征交互分析
advanced_explainer.feature_interaction_analysis(rf_model, X_test, feature_names)

# 反事实解释
counterfactuals = advanced_explainer.counterfactual_explanations(
    rf_model, X_test, y_test, feature_names
)

class BusinessInterpreter:
    """业务导向的模型解释器"""

    def __init__(self):
        self.business_rules = {}
        self.compliance_checks = {}

    def create_business_friendly_explanations(self, model, X, y, feature_names,
                                           customer_data=None, business_context=None):
        """创建业务友好的解释"""
        explanations = {}

        # 1. 监管合规检查
        compliance_report = self._regulatory_compliance_check(model, X, feature_names)
        explanations['compliance'] = compliance_report

        # 2. 业务规则对齐
        alignment_analysis = self._business_rule_alignment(model, X, feature_names)
        explanations['business_alignment'] = alignment_analysis

        # 3. 客户沟通模板
        communication_templates = self._create_communication_templates(model, X, y, feature_names)
        explanations['communication'] = communication_templates

        # 4. 风险洞察报告
        risk_insights = self._generate_risk_insights(model, X, y, feature_names)
        explanations['risk_insights'] = risk_insights

        return explanations

    def _regulatory_compliance_check(self, model, X, feature_names):
        """监管合规检查"""
        compliance_issues = []

        # 检查是否使用敏感特征
        sensitive_features = ['race', 'gender', 'age', 'religion', 'nationality']
        used_sensitive_features = []

        for feature in feature_names:
            for sensitive in sensitive_features:
                if sensitive in feature.lower():
                    used_sensitive_features.append(feature)

        if used_sensitive_features:
            compliance_issues.append({
                'issue': '使用敏感特征',
                'features': used_sensitive_features,
                'severity': '高',
                'recommendation': '移除或严格监控这些特征的使用'
            })

        # 检查特征重要性合理性
        if hasattr(model, 'feature_importances_'):
            importance_scores = model.feature_importances_
            top_features = [feature_names[i] for i in np.argsort(importance_scores)[-5:][::-1]]

            # 检查是否与业务常识一致
            business_critical = ['credit_score', 'income', 'debt']
            missing_critical = [feat for feat in business_critical
                              if not any(feat in top_feat for top_feat in top_features)]

            if missing_critical:
                compliance_issues.append({
                    'issue': '关键业务特征重要性不足',
                    'missing_features': missing_critical,
                    'severity': '中',
                    'recommendation': '检查模型是否捕获了关键业务逻辑'
                })

        return {
            'issues': compliance_issues,
            'status': '通过' if not compliance_issues else '需审查'
        }

    def _business_rule_alignment(self, model, X, feature_names):
        """业务规则对齐分析"""
        alignment_results = {}

        # 定义业务规则期望
        business_expectations = {
            'credit_score': {'direction': 'negative', 'strength': 'strong'},
            'income': {'direction': 'negative', 'strength': 'strong'},
            'debt_to_income': {'direction': 'positive', 'strength': 'strong'},
            'years_employed': {'direction': 'negative', 'strength': 'medium'}
        }

        # 分析模型与业务规则的一致性
        consistency_scores = {}

        for feature, expectation in business_expectations.items():
            # 找到对应的特征
            matching_features = [f for f in feature_names if feature in f.lower()]

            if matching_features:
                actual_feature = matching_features[0]
                feature_idx = feature_names.index(actual_feature)

                # 分析特征影响方向
                if hasattr(model, 'coef_'):
                    # 线性模型
                    coef = model.coef_[0][feature_idx]
                    actual_direction = 'negative' if coef < 0 else 'positive'
                else:
                    # 使用SHAP分析方向
                    try:
                        import shap
                        explainer = shap.TreeExplainer(model)
                        shap_values = explainer.shap_values(X)
                        mean_shap = np.mean(shap_values[1][:, feature_idx] if isinstance(shap_values, list) else shap_values[:, feature_idx])
                        actual_direction = 'negative' if mean_shap < 0 else 'positive'
                    except:
                        actual_direction = 'unknown'

                # 计算一致性
                expected_direction = expectation['direction']
                consistent = (actual_direction == expected_direction)
                consistency_scores[feature] = {
                    'expected': expected_direction,
                    'actual': actual_direction,
                    'consistent': consistent,
                    'feature_used': actual_feature
                }

        alignment_results['feature_consistency'] = consistency_scores
        alignment_results['alignment_score'] = sum([1 for v in consistency_scores.values() if v['consistent']]) / len(consistency_scores)

        return alignment_results

    def _create_communication_templates(self, model, X, y, feature_names):
        """创建客户沟通模板"""
        templates = {}

        # 批准决策模板
        approval_template = """
        恭喜！您的贷款申请已获得批准。

        决策主要基于以下积极因素：
        {positive_factors}

        建议继续保持良好的信用习惯。
        """

        # 拒绝决策模板
        rejection_template = """
        感谢您的申请。经过综合评估，我们暂时无法批准本次贷款。

        主要考虑因素包括：
        {negative_factors}

        建议改进方向：
        {improvement_suggestions}
        """

        templates['approval'] = approval_template
        templates['rejection'] = rejection_template

        # 生成具体案例
        sample_explanations = self._generate_sample_explanations(model, X, y, feature_names)
        templates['examples'] = sample_explanations

        return templates

    def _generate_sample_explanations(self, model, X, y, feature_names):
        """生成样本解释"""
        sample_explanations = {}

        # 选择几个代表性样本
        indices = [0, 1, 2]  # 简单选择前三个样本

        for idx in indices:
            explanation = self._explain_single_decision(model, X.iloc[idx:idx+1], y.iloc[idx], feature_names)
            sample_explanations[f'sample_{idx}'] = explanation

        return sample_explanations

    def _explain_single_decision(self, model, instance, true_label, feature_names):
        """解释单个决策"""
        explanation = {}

        # 获取预测
        if hasattr(model, 'predict_proba'):
            proba = model.predict_proba(instance)[0]
            prediction = 1 if proba[1] > 0.5 else 0
            confidence = max(proba)
        else:
            prediction = model.predict(instance)[0]
            confidence = 1.0

        explanation['prediction'] = prediction
        explanation['confidence'] = confidence
        explanation['true_label'] = true_label

        # 分析关键因素
        key_factors = self._identify_key_factors(model, instance, feature_names)
        explanation['key_factors'] = key_factors

        # 生成自然语言解释
        nl_explanation = self._generate_natural_language(key_factors, prediction, true_label)
        explanation['natural_language'] = nl_explanation

        return explanation

    def _identify_key_factors(self, model, instance, feature_names):
        """识别关键影响因素"""
        try:
            import shap

            # 使用SHAP分析
            explainer = shap.TreeExplainer(model)
            shap_values = explainer.shap_values(instance)

            if isinstance(shap_values, list):
                shap_values = shap_values[1]  # 取正类SHAP值

            # 获取特征贡献
            contributions = {}
            for i, feature in enumerate(feature_names):
                contributions[feature] = shap_values[0, i]

            # 排序并返回最重要的因素
            sorted_contributions = sorted(contributions.items(), key=lambda x: abs(x[1]), reverse=True)
            return sorted_contributions[:3]  # 返回前3个关键因素

        except:
            # 回退方法：使用特征重要性
            if hasattr(model, 'feature_importances_'):
                importances = model.feature_importances_
                feature_importance = list(zip(feature_names, importances))
                sorted_importance = sorted(feature_importance, key=lambda x: x[1], reverse=True)
                return [(feat, imp * 0.1) for feat, imp in sorted_importance[:3]]  # 简化处理
            else:
                return [('无法分析', 0)]

    def _generate_natural_language(self, key_factors, prediction, true_label):
        """生成自然语言解释"""
        if prediction == 1:  # 预测违约
            explanation = "本次申请风险评估较高，主要因为：\n"
            for factor, impact in key_factors:
                if impact > 0:
                    explanation += f"• {factor} 增加了违约风险\n"
                else:
                    explanation += f"• {factor} 未能充分降低风险\n"
        else:  # 预测正常
            explanation = "本次申请风险评估良好，主要因为：\n"
            for factor, impact in key_factors:
                if impact < 0:
                    explanation += f"• {factor} 降低了违约风险\n"
                else:
                    explanation += f"• {factor} 表现正常\n"

        return explanation

    def _generate_risk_insights(self, model, X, y, feature_names):
        """生成风险洞察报告"""
        insights = {}

        # 特征分布分析
        risk_by_feature = self._analyze_risk_by_feature(model, X, y, feature_names)
        insights['feature_analysis'] = risk_by_feature

        # 客户分群洞察
        segmentation_insights = self._customer_segmentation_insights(model, X, y, feature_names)
        insights['segmentation'] = segmentation_insights

        # 趋势分析
        trend_analysis = self._risk_trend_analysis(model, X, y, feature_names)
        insights['trends'] = trend_analysis

        return insights

    def _analyze_risk_by_feature(self, model, X, y, feature_names):
        """按特征分析风险"""
        risk_analysis = {}

        # 选择几个重要特征进行分析
        important_features = ['credit_score', 'debt_to_income', 'income']

        for feature_pattern in important_features:
            matching_features = [f for f in feature_names if feature_pattern in f.lower()]

            if matching_features:
                feature = matching_features[0]
                feature_values = X[feature]

                # 分析不同分位的风险率
                quantiles = [0.25, 0.5, 0.75]
                risk_by_quantile = {}

                for q in quantiles:
                    threshold = feature_values.quantile(q)
                    if feature_pattern in ['credit_score']:
                        # 高信用分数低风险
                        high_risk_group = feature_values < threshold
                    else:
                        high_risk_group = feature_values > threshold

                    risk_rate = y[high_risk_group].mean() if high_risk_group.any() else 0
                    risk_by_quantile[f'Q{q}'] = risk_rate

                risk_analysis[feature] = risk_by_quantile

        return risk_analysis

# 使用业务解释器
business_interpreter = BusinessInterpreter()
business_explanations = business_interpreter.create_business_friendly_explanations(
    rf_model, X_test, y_test, feature_names
)

print("=== 业务可解释性分析报告 ===\n")

# 显示合规检查结果
compliance = business_explanations['compliance']
print("1. 监管合规检查:")
print(f"   状态: {compliance['status']}")
if compliance['issues']:
    for issue in compliance['issues']:
        print(f"   ⚠️ {issue['issue']}: {issue['features']}")
        print(f"     建议: {issue['recommendation']}")

# 显示业务规则对齐
alignment = business_explanations['business_alignment']
print(f"\n2. 业务规则对齐度: {alignment['alignment_score']:.1%}")
for feature, consistency in alignment['feature_consistency'].items():
    status = "✓" if consistency['consistent'] else "✗"
    print(f"   {status} {feature}: 期望{consistency['expected']}, 实际{consistency['actual']}")

# 显示样本解释
print("\n3. 样本决策解释:")
for sample_key, explanation in business_explanations['communication']['examples'].items():
    print(f"\n{sample_key}:")
    print(f"   预测: {'违约' if explanation['prediction'] == 1 else '正常'}")
    print(f"   置信度: {explanation['confidence']:.1%}")
    print(f"   解释: {explanation['natural_language']}")
