内容复习---单细胞空间分析之NMF

####zhaoyunfei
####20251115
library(Seurat)
library(NMF)
library(cluster)
library(dplyr)
library(ggplot2)

#' @param seurat_obj Seurat对象
#' @param k_values k值范围，默认2:18
#' @param n_top_genes 每个程序保留的top基因数，默认50
#' @return 包含所有NMF程序结果的列表
run_multiple_k_nmf <- function(seurat_obj, k_values = 2:18, n_top_genes = 50) {
  # 获取归一化的表达矩阵
  norm_data <- GetAssayData(seurat_obj, slot = "data")
  norm_data <- as.matrix(norm_data)

  # 移除零表达的基因
  norm_data <- norm_data[rowSums(norm_data) > 0, ]

  nmf_results <- list()
  program_counter <- 1

  for(k in k_values) {
    cat("Running NMF with k =", k, "\n")

    tryCatch({
      # 运行NMF
      nmf_fit <- nmf(norm_data, rank = k, method = "brunet", nrun = 10)

      # 提取特征基因矩阵
      feature_matrix <- basis(nmf_fit)

      # 为每个程序提取top基因
      for(i in 1:k) {
        program_genes <- rownames(feature_matrix)[order(feature_matrix[, i], decreasing = TRUE)[1:n_top_genes]]

        nmf_results[[program_counter]] <- list(
          k_value = k,
          program_id = paste0("k", k, "_program", i),
          genes = program_genes,
          scores = feature_matrix[program_genes, i]
        )
        program_counter <- program_counter + 1
      }
    }, error = function(e) {
      cat("Error with k =", k, ":", e$message, "\n")
    })
  }

  return(nmf_results)
}

#' @param setA 基因集合A
#' @param setB 基因集合B
#' @return Jaccard index
jaccard_index <- function(setA, setB) {
  intersection <- length(intersect(setA, setB))
  union <- length(union(setA, setB))
  return(intersection / union)
}

#' 筛选稳健的NMF程序
#' @param nmf_results NMF结果列表
#' @param min_k_overlap 不同k值间最小基因重叠数，默认35
#' @param redundancy_threshold 冗余阈值，默认0.1
#' @param cross_sample_threshold 跨样本一致性阈值，默认0.1
#' @return 筛选后的NMF程序列表
filter_robust_programs <- function(nmf_results, min_k_overlap = 35,
                                  redundancy_threshold = 0.1,
                                  cross_sample_threshold = 0.1) {

  # 按样本分组（这里假设所有程序来自同一个样本，如需多样本需调整）
  programs_by_k <- split(nmf_results, sapply(nmf_results, function(x) x$k_value))

  robust_programs <- list()
  retained_programs <- c()

  # 第一步：样本内筛选 - 不同k值间的重叠
  for(program in nmf_results) {
    program_genes <- program$genes

    # 检查与其他k值的程序的重叠
    overlap_count <- 0
    for(other_program in nmf_results) {
      if(other_program$k_value != program$k_value) {
        overlap <- length(intersect(program_genes, other_program$genes))
        if(overlap >= min_k_overlap) {
          overlap_count <- overlap_count + 1
          break
        }
      }
    }

    if(overlap_count > 0) {
      robust_programs[[length(robust_programs) + 1]] <- program
      retained_programs <- c(retained_programs, program$program_id)
    }
  }

  # 第二步：去除冗余程序
  non_redundant_programs <- list()
  processed_pairs <- character()

  for(i in 1:length(robust_programs)) {
    redundant <- FALSE
    prog_i <- robust_programs[[i]]

    for(j in 1:length(robust_programs)) {
      if(i != j) {
        prog_j <- robust_programs[[j]]
        pair_id <- paste(sort(c(prog_i$program_id, prog_j$program_id)), collapse = "_")

        if(!pair_id %in% processed_pairs) {
          jaccard <- jaccard_index(prog_i$genes, prog_j$genes)
          if(jaccard >= redundancy_threshold) {
            redundant <- TRUE
            # 保留基因数较多或得分较高的程序
            if(length(prog_i$genes) < length(prog_j$genes) ||
               mean(prog_i$scores) < mean(prog_j$scores)) {
              break
            }
          }
          processed_pairs <- c(processed_pairs, pair_id)
        }
      }
    }

    if(!redundant) {
      non_redundant_programs[[length(non_redundant_programs) + 1]] <- prog_i
    }
  }

  return(non_redundant_programs)
}

#' 聚类NMF程序生成共识MPs
#' @param filtered_programs 筛选后的NMF程序
#' @param min_overlap 最小重叠阈值，默认0.1
#' @return 共识MPs列表
generate_consensus_mps <- function(filtered_programs, min_overlap = 0.1) {
  if(length(filtered_programs) == 0) {
    stop("No programs to cluster")
  }

  # 创建基因集合列表
  gene_sets <- lapply(filtered_programs, function(x) x$genes)
  names(gene_sets) <- sapply(filtered_programs, function(x) x$program_id)

  # 计算杰卡德距离矩阵
  n_programs <- length(gene_sets)
  dist_matrix <- matrix(0, nrow = n_programs, ncol = n_programs)

  for(i in 1:n_programs) {
    for(j in 1:n_programs) {
      if(i != j) {
        jaccard <- jaccard_index(gene_sets[[i]], gene_sets[[j]])
        dist_matrix[i, j] <- 1 - jaccard  # 转换为距离
      }
    }
  }

  # 使用层次聚类
  hc <- hclust(as.dist(dist_matrix), method = "average")

  # 自动确定聚类数量（这里使用简单的启发式方法）
  # 您可以根据需要调整聚类切割高度
  clusters <- cutree(hc, h = 0.8)  # 调整h参数以获得合适的聚类数

  # 生成共识MPs
  consensus_mps <- list()
  unique_clusters <- unique(clusters)

  for(cluster_id in unique_clusters) {
    cluster_programs <- which(clusters == cluster_id)
    cluster_genes <- unique(unlist(lapply(filtered_programs[cluster_programs], function(x) x$genes)))

    # 计算基因频率
    gene_freq <- table(unlist(lapply(filtered_programs[cluster_programs], function(x) x$genes)))

    consensus_mps[[paste0("MP", cluster_id)]] <- list(
      genes = names(sort(gene_freq, decreasing = TRUE)),
      gene_frequency = sort(gene_freq, decreasing = TRUE),
      n_programs = length(cluster_programs)
    )
  }

  return(consensus_mps)
}

#' 计算MPs的GSVA分数
#' @param seurat_obj Seurat对象
#' @param consensus_mps 共识MPs
#' @return 包含MP分数的矩阵
calculate_mp_scores <- function(seurat_obj, consensus_mps) {
  # 简化版的MP评分计算（实际GSVA需要更复杂的实现）
  # 这里使用简单的平均表达量作为示例

  norm_data <- GetAssayData(seurat_obj, slot = "data")
  mp_scores <- matrix(0, nrow = length(consensus_mps), ncol = ncol(norm_data))
  rownames(mp_scores) <- names(consensus_mps)
  colnames(mp_scores) <- colnames(norm_data)

  for(mp_name in names(consensus_mps)) {
    mp_genes <- consensus_mps[[mp_name]]$genes[1:50]  # 取前50个基因
    available_genes <- mp_genes[mp_genes %in% rownames(norm_data)]

    if(length(available_genes) > 0) {
      mp_scores[mp_name, ] <- colMeans(norm_data[available_genes, , drop = FALSE])
    }
  }

  return(mp_scores)
}

# 主分析流程
main_nmf_analysis <- function(seurat_obj) {
  cat("Step 1: Running multiple k NMF\n")
  nmf_results <- run_multiple_k_nmf(seurat_obj)

  cat("Step 2: Filtering robust programs\n")
  filtered_programs <- filter_robust_programs(nmf_results)

  cat("Step 3: Generating consensus MPs\n")
  consensus_mps <- generate_consensus_mps(filtered_programs)

  cat("Step 4: Calculating MP scores\n")
  mp_scores <- calculate_mp_scores(seurat_obj, consensus_mps)

  cat("Step 5: Assigning MP labels to spots\n")
  # 为每个spot分配MP标签
  mp_assignments <- apply(mp_scores, 2, function(x) {
    if(all(is.na(x)) || max(x) == 0) return(NA)
    rownames(mp_scores)[which.max(x)]
  })

  # 将结果添加到Seurat对象
  seurat_obj$MP_assignment <- mp_assignments

  # 计算每个MP在每个样本中的比例
  sample_mp_proportions <- table(seurat_obj$MP_assignment, seurat_obj$orig.ident)
  sample_mp_proportions <- prop.table(sample_mp_proportions, margin = 2)

  # 计算MP间的相关性
  mp_correlations <- cor(t(sample_mp_proportions), method = "spearman")

  return(list(
    seurat_obj = seurat_obj,
    nmf_results = nmf_results,
    filtered_programs = filtered_programs,
    consensus_mps = consensus_mps,
    mp_scores = mp_scores,
    sample_mp_proportions = sample_mp_proportions,
    mp_correlations = mp_correlations
  ))
}

# 使用示例
# Seurat对象名为 seurat_obj
# results <- main_nmf_analysis(seurat_obj)

# 保存结果
# saveRDS(results, "nmf_analysis_results.rds")

# 可视化MP相关性
plot_mp_correlations <- function(mp_correlations) {
  corr_melt <- reshape2::melt(mp_correlations)
  ggplot(corr_melt, aes(x = Var1, y = Var2, fill = value)) +
    geom_tile() +
    scale_fill_gradient2(low = "blue", high = "red", mid = "white",
                        midpoint = 0, limits = c(-1, 1)) +
    theme_minimal() +
    theme(axis.text.x = element_text(angle = 45, hjust = 1)) +
    labs(x = "Meta-Programs", y = "Meta-Programs", fill = "Correlation")
}

# 可视化MP在样本中的分布
plot_mp_distribution <- function(sample_mp_proportions) {
  dist_melt <- reshape2::melt(sample_mp_proportions)
  ggplot(dist_melt, aes(x = Var2, y = value, fill = Var1)) +
    geom_bar(stat = "identity", position = "fill") +
    theme_minimal() +
    theme(axis.text.x = element_text(angle = 45, hjust = 1)) +
    labs(x = "Samples", y = "Proportion", fill = "Meta-Programs")
}
