（46）STM32——FATFS文件系统实验

#include "sys.h"
#include "delay.h"
#include "usart.h"
#include "led.h"
#include "lcd.h"
#include "key.h"
#include "sram.h"
#include "malloc.h"
#include "usmart.h"
#include "sdio_sdcard.h"
#include "malloc.h"
#include "w25qxx.h"
#include "ff.h"
#include "exfuns.h"
int main(void)
{
	FIL fp;
	FRESULT result;
	UINT bww;
	char buf[100];
 	u32 total,free;
	u8 t=0;
	u8 res=0;

	NVIC_PriorityGroupConfig(NVIC_PriorityGroup_2);//设置系统中断优先级分组2
	delay_init(168);  //初始化延时函数
	uart_init(115200);		//初始化串口波特率为115200
	LED_Init();					//初始化LED
	usmart_dev.init(84);		//初始化USMART
 	LCD_Init();					//LCD初始化
 	KEY_Init();					//按键初始化
	W25QXX_Init();				//初始化W25Q128
	my_mem_init(SRAMIN);		//初始化内部内存池
	my_mem_init(SRAMCCM);		//初始化CCM内存池

 	POINT_COLOR=RED;//设置字体为红色
	LCD_ShowString(30,90,200,16,16,"Explorer STM32F4");
	LCD_ShowString(30,110,200,16,16,"FATFS TEST");
	LCD_ShowString(30,130,200,16,16,"Use USMART for test");
 	while(SD_Init())//检测不到SD卡
	{
		LCD_ShowString(30,150,200,16,16,"SD Card Error!");
		delay_ms(500);
		LCD_ShowString(30,150,200,16,16,"Please Check! ");
		delay_ms(500);
		LED0=!LED0;//DS0闪烁
	}
 	exfuns_init();							//为fatfs相关变量申请内存
  	f_mount(fs[0],"0:",1); 					//挂载SD卡
 	res=f_mount(fs[1],"1:",1); 				//挂载FLASH.
	if(res==0X0D)//FLASH磁盘,FAT文件系统错误,重新格式化FLASH
	{
		LCD_ShowString(30,150,200,16,16,"Flash Disk Formatting...");	//格式化FLASH
		res=f_mkfs("1:",1,4096);//格式化FLASH,1,盘符;1,不需要引导区,8个扇区为1个簇
		if(res==0)
		{
			f_setlabel((const TCHAR *)"1:ALIENTEK");	//设置Flash磁盘的名字为：ALIENTEK
			LCD_ShowString(30,150,200,16,16,"Flash Disk Format Finish");	//格式化完成
		}else LCD_ShowString(30,150,200,16,16,"Flash Disk Format Error ");	//格式化失败
		delay_ms(1000);
	}
	LCD_Fill(30,150,240,150+16,WHITE);		//清除显示
	while(exf_getfree("0",&total,&free))	//得到SD卡的总容量和剩余容量
	{
		LCD_ShowString(30,150,200,16,16,"SD Card Fatfs Error!");
		delay_ms(200);
		LCD_Fill(30,150,240,150+16,WHITE);	//清除显示
		delay_ms(200);
		LED0=!LED0;//DS0闪烁
	}
 	POINT_COLOR=BLUE;//设置字体为蓝色
	LCD_ShowString(30,150,200,16,16,"FATFS OK!");
	LCD_ShowString(30,170,200,16,16,"SD Total Size:     MB");
	LCD_ShowString(30,190,200,16,16,"SD  Free Size:     MB");
 	LCD_ShowNum(30+8*14,170,total>>10,5,16);				//显示SD卡总容量 MB
 	LCD_ShowNum(30+8*14,190,free>>10,5,16);					//显示SD卡剩余容量 MB

	result  = f_open (& fp, "0:1.txt", FA_CREATE_ALWAYS | FA_WRITE);

	f_write (&fp," test" , 50, & bww);

	f_close(&fp);

	result  = f_open (& fp, "0:1.txt", FA_READ);

	f_read (& fp, buf,100, & bww);

	f_close(&fp);

	LCD_ShowString(30,210,230,16,16,(u8 *)buf);
	while(1)
	{
		t++;
		delay_ms(200);
		LED0=!LED0;
	}
}
