[Blazor] 基于MQTTnet实现MQTT客户端

作者头像
科控物联
发布2023-02-28 16:26:17
发布2023-02-28 16:26:17
2.7K0
举报
文章被收录于专栏:科控自动化科控自动化

整个项目结构很简单

MQTT_Connector类库就只有2个文件。直接上代码

Worker用于实现长时间运行的类。

P.S.

BackgroundService :用于实现长时间运行的 IHostedService 的基类。

代码语言:javascript
复制
using MQTTnet;
using MQTTnet.Client;
using System.Text;
using System.Text.Json;

namespace MQTT_Connector;

public class Worker : BackgroundService
{
    private readonly MQTTService MqttService;
    private readonly MqttFactory MqttFactory;
    private readonly ILogger<Worker> Logger;
    public  TObject DumpToConsole<TObject>( TObject @object)
    {
        var output = "NULL";
        if (@object != null)
        {
            output = JsonSerializer.Serialize(@object, new JsonSerializerOptions
            {
                WriteIndented = true
            });
        }

        Logger.LogInformation($"[{@object?.GetType().Name}]:\r\n{output}");
        return @object;
    }
    public Worker(MQTTService mQTTService, ILogger<Worker> logger)
    {
        this.MqttService = mQTTService;
        this.MqttFactory = new MqttFactory();
        this.Logger = logger;
    }

    public async Task Update(string message)
    {
        await MqttService.RefreshAsync(message);
    }

    protected override async Task ExecuteAsync(CancellationToken stoppingToken)
    {

        using IMqttClient mqttClient = MqttFactory.CreateMqttClient();        // 1. 创建 MQTT 客户端
        // 2 . 设置 MQTT 客户端选项 (// 设置服务器端地址// 设置鉴权参数// 创建选项)
        var mqttClientOptions = new MqttClientOptionsBuilder()
            .WithTcpServer("localhost")
           // .WithCredentials( "admin","public")
            .Build();

        var response = await mqttClient.ConnectAsync(mqttClientOptions, CancellationToken.None);
        Logger.LogInformation($"The MQTT client is connected.");
        DumpToConsole(response);

         var mqttSubscribeOptions = MqttFactory.CreateSubscribeOptionsBuilder()
            .WithTopicFilter(f => { f.WithTopic("#"); })
            .Build();

      var subscribe=  await mqttClient.SubscribeAsync(mqttSubscribeOptions, CancellationToken.None);

        //Logger.LogInformation($"{string.Join("/",mqttSubscribeOptions.TopicFilters)}");
        DumpToConsole(subscribe);
        mqttClient.ApplicationMessageReceivedAsync += async delegate (MqttApplicationMessageReceivedEventArgs args)
        {
            var mqttMessage = "";
            if (args.ApplicationMessage.Payload is null)
            {
                mqttMessage = "Empty message";
            }
            else
            {
                mqttMessage = Encoding.UTF8.GetString(args.ApplicationMessage.Payload);
            }

            //Console.WriteLine("Console Response = {0}", mqttMessage);
            Logger.LogInformation($"{args.ApplicationMessage.Topic} ={ mqttMessage}" );
            mqttMessage = ($"{args.ApplicationMessage.Topic} ={mqttMessage}");

            await Update(mqttMessage).ConfigureAwait(false);
        };

        while (!stoppingToken.IsCancellationRequested)
        {
            try
            {
               // Logger.LogInformation("心跳时间5秒");
                if (!await mqttClient.TryPingAsync(cancellationToken: stoppingToken))
                {
                    await mqttClient.ConnectAsync(mqttClientOptions, CancellationToken.None);
                    // Subscribe to topics when session is clean etc.
                    Logger.LogInformation("The MQTT client is connected.");
                    await mqttClient.SubscribeAsync(mqttSubscribeOptions, CancellationToken.None);

                }
                else
                {
                     Logger.LogInformation("心跳测试OK");
                }
            }
            catch (Exception ex)
            {
                // Some message here
                Logger.LogInformation(ex.Message);
            }
            finally
            {
                // Delay 5 seconds
             //   Logger.LogInformation($" Delay 5 seconds");
                await Task.Delay(5 * 1000, stoppingToken);
            }
        }
    }
}

MQTTService主要是订阅信息的解析。

代码语言:javascript
复制
namespace MQTT_Connector
{
    public class MQTTService
    {
        public string? Message { get; set; }
        public event Func<Task> Notify;

        public async Task RefreshAsync(string message)
        {
            if (Notify is { })
            {
                Message = message;
                await Notify.Invoke();
            }
        }
    }
}

Blazor前端项目基于官方模板生成,引入MQTT_Connector项目

注册服务

代码语言:javascript
复制
builder.Services.AddHostedService<Worker>();
builder.Services.AddSingleton<MQTTService>();

添加页面

代码语言:javascript
复制
@inject MQTTService mqttService
@implements IDisposable
@page "/dashboard"
<PageTitle>Dashboard</PageTitle>
<div>
    <h1>Message</h1>

    <p role="status">Current message: @mqttService.Message</p>
</div>

@code {
    protected override  void OnInitialized() => mqttService.Notify += OnNotify;

    public async Task OnNotify() => await InvokeAsync(() =>{StateHasChanged();});

    public void Dispose()
    {
        mqttService.Notify -= OnNotify;
    }
}

运行

视频演示:http://mpvideo.qpic.cn/0bc3gmabkaaaxeahawpaqrrvam6dcuzqafia.f10002.mp4?dis_k=f85c715e3293312c32e0b91c20c4df82&dis_t=1677572713&play_scene=10400&vid=wxv_2785993811067076608&format_id=10002&support_redirect=0&mmversion=false
