算力机房动环改造：UDP协议以太网温湿度变送器多并发采集实现思路

┌─────────────────────────────────────────────────────────────────────┐
│                        算力机房动环采集架构                          │
├─────────────────────────────────────────────────────────────────────┤
│                                                                     │
│  ┌─────────────────────────────────────────────────────────────┐   │
│  │ 采集接入层（多节点，每节点负责一个 Pod/Row）                  │   │
│  │  ┌─────────┐  ┌─────────┐  ┌─────────┐  ┌─────────┐       │   │
│  │  │ 节点 A   │  │ 节点 B   │  │ 节点 C   │  │ 节点 D   │ ... │   │
│  │  │ 128台    │  │ 128台    │  │ 128台    │  │ 128台    │       │   │
│  │  │ 4×25G   │  │ 4×25G   │  │ 4×25G   │  │ 4×25G   │       │   │
│  │  └────┬────┘  └────┬────┘  └────┬────┘  └────┬────┘       │   │
│  └───────┼────────────┼────────────┼────────────┼────────────┘   │
│          │            │            │            │                  │
│  ┌───────▼────────────▼────────────▼────────────▼────────────┐   │
│  │              汇聚层（Kafka / Pulsar）                       │   │
│  │        消息队列解耦采集与存储，削峰填谷                      │   │
│  └───────────────────────┬────────────────────────────────────┘   │
│                          │                                        │
│  ┌───────────────────────▼────────────────────────────────────┐   │
│  │              处理层（流式计算 + 规则引擎）                    │   │
│  │  - 实时聚合（每机柜平均/最大/最小）                          │   │
│  │  - 异常检测（梯度突变、连续越限）                            │   │
│  │  - 数据补全（插值、标记缺失）                                │   │
│  └──────────┬────────────────────────┬────────────────────────┘   │
│             │                        │                              │
│  ┌──────────▼──────┐      ┌─────────▼────────┐                    │
│  │  时序数据库      │      │  告警/联动系统    │                    │
│  │  InfluxDB集群   │      │  大屏/Webhook     │                    │
│  └─────────────────┘      └──────────────────┘                    │
└─────────────────────────────────────────────────────────────────────┘

# 1. 增大 UDP 接收缓冲区
sysctl -w net.core.rmem_max=268435456      # 256MB
sysctl -w net.core.rmem_default=16777216   # 16MB
sysctl -w net.ipv4.udp_mem="262144 327680 393216"  # min/pressure/max (pages)

# 2. 增大套接字接收队列长度
sysctl -w net.core.netdev_max_backlog=16384
sysctl -w net.core.somaxconn=8192

# 3. 减少 softirq 延迟
sysctl -w net.core.dev_weight=600
sysctl -w net.core.busy_poll=50
sysctl -w net.core.busy_read=50

# 4. 启用 RSS（接收侧缩放）和 RPS（软件 RPS）
# 查看网卡队列数
ls /sys/class/net/eth0/queues/
# 配置 RPS（将软中断分散到多个 CPU）
echo ffff > /sys/class/net/eth0/queues/rx-0/rps_cpus
echo 32768 > /sys/class/net/eth0/queues/rx-0/rps_flow_cnt

# 5. 启用 XPS（发送侧）
echo ffff > /sys/class/net/eth0/queues/tx-0/xps_cpus

# 6. 中断亲和性绑定（irqbalance 或手动）
# 查看中断号
cat /proc/interrupts | grep eth0
# 绑定到特定 CPU（示例）
echo 2 > /proc/irq/123/smp_affinity  # 绑定到 CPU 1

"""
collector_node.py - 多进程 UDP 采集节点
"""

import asyncio
import socket
import struct
import multiprocessing as mp
import signal
import os
from dataclasses import dataclass
from kafka import KafkaProducer
import json

NUM_WORKERS = mp.cpu_count()  # 通常 8~32 核
UDP_PORT = 9000
KAFKA_SERVERS = ["kafka-1:9092", "kafka-2:9092", "kafka-3:9092"]

@dataclass
class RawReading:
    dev_id: str
    seq: int
    temperature: float
    humidity: float
    timestamp: float
    recv_ts: float
    worker_pid: int

class Worker:
    def __init__(self, worker_id: int, cpu_affinity: int):
        self.worker_id = worker_id
        self.cpu_affinity = cpu_affinity
        self.producer = None

    def setup_kafka(self):
        """每个 worker 独立的 Kafka producer（线程安全）"""
        self.producer = KafkaProducer(
            bootstrap_servers=KAFKA_SERVERS,
            value_serializer=lambda v: json.dumps(v).encode("utf-8"),
            acks=1,
            linger_ms=50,        # 批量发送
            batch_size=65536,
            compression_type="snappy",
            retries=3,
            max_in_flight_requests_per_connection=5
        )

    def parse_packet(self, data: bytes, addr: tuple, recv_ts: float) -> RawReading | None:
        if len(data) < 32:
            return None
        try:
            header, dev_id, seq, ts, temp_raw, hum_raw, status, crc = \
                struct.unpack_from(">HHHIHHBH", data, 0)
            if header != 0xAA55:
                return None
            return RawReading(
                dev_id=f"{addr[0]}:{dev_id}",
                seq=seq,
                temperature=temp_raw / 10.0 if temp_raw < 0x8000 else (temp_raw - 0x10000) / 10.0,
                humidity=hum_raw / 10.0,
                timestamp=ts,
                recv_ts=recv_ts,
                worker_pid=os.getpid()
            )
        except Exception:
            return None

    async def run(self):
        """Worker 主循环"""
        # CPU 亲和性绑定
        os.sched_setaffinity(0, {self.cpu_affinity})

        self.setup_kafka()

        # 创建 UDP socket，启用 SO_REUSEPORT
        sock = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)
        sock.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEPORT, 1)
        sock.setsockopt(socket.SOL_SOCKET, socket.SO_RCVBUF, 16 * 1024 * 1024)  # 16MB
        sock.bind(("0.0.0.0", UDP_PORT))
        sock.setblocking(False)

        loop = asyncio.get_event_loop()
        print(f"Worker {self.worker_id} (PID={os.getpid()}) bound to CPU {self.cpu_affinity}, port {UDP_PORT}")

        while True:
            try:
                data, addr = await loop.sock_recvfrom(sock, 1024)
                recv_ts = loop.time()
                reading = self.parse_packet(data, addr, recv_ts)
                if reading:
                    # 发送到 Kafka
                    self.producer.send(
                        "env_raw",
                        key=reading.dev_id.encode(),
                        value={
                            "dev_id": reading.dev_id,
                            "seq": reading.seq,
                            "temperature": reading.temperature,
                            "humidity": reading.humidity,
                            "timestamp": reading.timestamp,
                            "recv_ts": reading.recv_ts,
                            "worker_pid": reading.worker_pid
                        }
                    )
            except asyncio.CancelledError:
                break
            except Exception as e:
                print(f"Worker {self.worker_id} error: {e}")

        sock.close()
        self.producer.close()

def start_worker(worker_id: int, cpu_affinity: int):
    """子进程入口"""
    worker = Worker(worker_id, cpu_affinity)
    loop = asyncio.new_event_loop()
    asyncio.set_event_loop(loop)

    # 信号处理
    def shutdown():
        for task in asyncio.all_tasks(loop):
            task.cancel()
        loop.stop()

    loop.add_signal_handler(signal.SIGTERM, shutdown)
    loop.add_signal_handler(signal.SIGINT, shutdown)

    try:
        loop.run_until_complete(worker.run())
    finally:
        loop.close()

def main():
    """主进程：启动所有 worker"""
    print(f"Starting {NUM_WORKERS} workers for UDP port {UDP_PORT}")

    processes = []
    for i in range(NUM_WORKERS):
        p = mp.Process(target=start_worker, args=(i, i % mp.cpu_count()))
        p.start()
        processes.append(p)
        print(f"Spawned worker {i} (PID={p.pid})")

    def shutdown_all(sig, frame):
        print("Shutting down...")
        for p in processes:
            p.terminate()
        for p in processes:
            p.join(timeout=5)
            if p.is_alive():
                p.kill()
        exit(0)

    signal.signal(signal.SIGTERM, shutdown_all)
    signal.signal(signal.SIGINT, shutdown_all)

    # 主进程等待
    for p in processes:
        p.join()

if __name__ == "__main__":
    main()

# 查看每个 worker 的 CPU 使用情况
top -H -p $(pgrep -f collector_node | head -1)

# 查看 UDP 接收统计
watch -n 1 'cat /proc/net/udp | wc -l'
nstat -az | grep UdpRcv

# 查看软中断分布
cat /proc/softirqs | grep NET_RX

# 查看套接字接收队列
ss -lunpem | grep 9000

# 压测：用 pktgen 模拟 UDP 流量
# 单节点模拟 512 台 × 2s 周期
python pktgen_sim.py --count 512 --interval 2 --port 9000 --target 10.20.1.100

"""
packet_tracker.py - 丢包检测
"""

from collections import defaultdict
from dataclasses import dataclass, field

@dataclass
class DeviceState:
    last_seq: int = -1
    lost_count: int = 0
    received_count: int = 0
    last_recv_ts: float = 0.0
    gap_history: list = field(default_factory=list)  # 最近 N 次丢包 burst 大小

class PacketTracker:
    def __init__(self, gap_threshold=5, window_size=100):
        self.devices: dict[str, DeviceState] = {}
        self.gap_threshold = gap_threshold  # 序号跳变超过此值视为回绕或严重丢包
        self.window_size = window_size

    def on_packet(self, dev_id: str, seq: int, recv_ts: float) -> dict:
        """返回丢包信息"""
        state = self.devices.get(dev_id)
        if state is None:
            state = DeviceState()
            self.devices[dev_id] = state
            state.last_seq = seq
            state.received_count = 1
            state.last_recv_ts = recv_ts
            return {"dev_id": dev_id, "lost": 0, "event": "first_packet"}

        state.received_count += 1
        state.last_recv_ts = recv_ts

        if seq == state.last_seq:
            return {"dev_id": dev_id, "lost": 0, "event": "duplicate"}

        # 处理序号回绕（16 位序号）
        expected = (state.last_seq + 1) & 0xFFFF
        if seq == expected:
            state.last_seq = seq
            return {"dev_id": dev_id, "lost": 0, "event": "ok"}

        # 计算跳变
        if seq > state.last_seq:
            gap = seq - state.last_seq - 1
        else:
            # 回绕
            gap = (0x10000 - state.last_seq) + seq - 1

        if gap > self.gap_threshold:
            # 序号跳变过大，可能是设备重启或严重丢包
            state.last_seq = seq
            return {"dev_id": dev_id, "lost": -1, "event": "seq_reset", "gap": gap}

        state.lost_count += gap
        state.gap_history.append(gap)
        if len(state.gap_history) > self.window_size:
            state.gap_history.pop(0)

        state.last_seq = seq
        return {"dev_id": dev_id, "lost": gap, "event": "gap", "total_lost": state.lost_count}

"""
stream_processor.py - Kafka 消费者 + 数据质量处理
"""

from kafka import KafkaConsumer, KafkaProducer
import json
from datetime import datetime, timedelta
from collections import defaultdict

consumer = KafkaConsumer(
    "env_raw",
    bootstrap_servers=["kafka-1:9092"],
    value_deserializer=lambda v: json.loads(v.decode("utf-8")),
    group_id="env_processor",
    auto_offset_reset="latest"
)

producer = KafkaProducer(
    bootstrap_servers=["kafka-1:9092"],
    value_serializer=lambda v: json.dumps(v).encode("utf-8")
)

# 设备状态缓存
device_cache = defaultdict(dict)
# 最近有效值（用于插值）
last_valid = {}

for msg in consumer:
    reading = msg.value
    dev_id = reading["dev_id"]

    # 1. 数据质量标记
    quality = "good"
    if reading["recv_ts"] - reading["timestamp"] > 10:
        quality = "clock_drift"

    # 2. 连续丢失检测（基于 recv_ts 间隔）
    last = last_valid.get(dev_id)
    if last:
        interval = reading["recv_ts"] - last["recv_ts"]
        expected_interval = 5.0  # 设备上报周期
        if interval > expected_interval * 2.5:
            # 中间有丢包
            missing_count = int(interval / expected_interval) - 1
            # 发送插值标记
            for i in range(1, missing_count + 1):
                interp_ts = last["recv_ts"] + i * expected_interval
                producer.send("env_interpolated", value={
                    "dev_id": dev_id,
                    "timestamp": interp_ts,
                    "temperature": None,  # 标记为插值缺失
                    "humidity": None,
                    "quality": "missing",
                    "missing_seq": i,
                    "total_missing": missing_count
                })

    # 3. 更新缓存
    last_valid[dev_id] = reading

    # 4. 发送到处理后的 topic
    producer.send("env_processed", value={
        "dev_id": dev_id,
        "seq": reading["seq"],
        "temperature": reading["temperature"],
        "humidity": reading["humidity"],
        "timestamp": reading["timestamp"],
        "recv_ts": reading["recv_ts"],
        "quality": quality
    })

接入交换机（每 ToR 48 端口）：
- 启用 IGMP Snooping（如果设备支持组播）
- 配置广播抑制：broadcast-suppression 10%
- 配置风暴控制：storm-control broadcast level 10
- PoE 功率预算：每端口 15.4W，总预算 370W（24 端口满配）
- 启用 LLDP：便于设备发现和拓扑
- QoS：为管理流量（UDP 9000）打 DSCP AF11

VLAN 规划：
- VLAN 10：计算网络（GPU 训练流量）
- VLAN 20：存储网络（NVMe over Fabrics）
- VLAN 30：动环管理（温湿度变送器）
- VLAN 40：IPMI/BMC

流量隔离：
- 动环 VLAN 独立，不与计算网络混跑
- 汇聚交换机上联带宽 ≥ 10Gbps（即使动环流量只有几 Mbps，也要避免拥塞）
- 如果 Spine-Leaf 架构，动环流量走独立 Leaf 对

┌─────────────┐
        │  Keepalived  │
        │  VIP: x.x.x.x│
        └──────┬──────┘
               │
     ┌─────────┼─────────┐
     │         │         │
┌────▼───┐ ┌──▼────┐ ┌──▼────┐
│ 主节点  │ │ 备节点 │ │ 备节点 │
│ (Active)│ │(Standby)│ │(Standby)│
└────────┘ └───────┘ └───────┘

VIP 漂移条件：
- 主节点进程挂掉
- 主节点网络不可达
- 主节点 UDP 接收丢包率 > 1%

设备侧：
- 设备配置主备双目标 IP（部分高端设备支持）
- 或：设备只发一个目标，VIP 漂移后自动切换

三层保障：
1. 设备本地存储：断网期间数据不丢
2. 采集节点 Kafka：消息持久化，多副本
3. 时序数据库：InfluxDB 多节点集群，数据冗余

恢复流程：
- 网络恢复 → 设备主动补传（如果支持）
- 或：采集节点从设备拉取历史（Modbus TCP 读取 Flash）
- 或：人工导出 CSV 补录
