独立配电柜集群监测：TCP/IP长连接，批量温湿度数据上传服务器

┌─────────────────────────────────────────────────────────────────────┐
│                        采集服务器（中心侧）                          │
│  ┌────────────────────────────────────────────────────────────────┐ │
│  │              TCP 长连接服务端（单端口 5020）                     │ │
│  │  ┌────────────┐  ┌────────────┐  ┌────────────┐              │ │
│  │  │ 连接管理器  │  │ 协议解析器  │  │ 数据分发器  │              │ │
│  │  │ 96 连接    │→│ 批量解包    │→│ 写时序库   │              │ │
│  │  │ KeepAlive  │  │ CRC 校验   │  │ 告警判断   │              │ │
│  │  │ 心跳检测   │  │ 序列号检测  │  │ 数据转发   │              │ │
│  │  └────────────┘  └────────────┘  └────────────┘              │ │
│  └────────────────────────────────────────────────────────────────┘ │
│                              │                                      │
│              ┌───────────────┼───────────────┐                      │
│              ▼               ▼               ▼                      │
│  ┌──────────────┐  ┌──────────────┐  ┌──────────────┐            │
│  │ 时序数据库    │  │  告警引擎    │  │  BA 平台接口  │            │
│  │  InfluxDB    │  │  越限判断    │  │  BACnet/MQTT │            │
│  └──────────────┘  └──────────────┘  └──────────────┘            │
└───────────────────────┬─────────────────────────────────────────────┘
                        │
                        ▼ (监测 VLAN)
┌─────────────────────────────────────────────────────────────────────┐
│                   配电柜集群（传感器侧）                              │
│                                                                     │
│  ┌─────────┐  ┌─────────┐  ┌─────────┐     ┌─────────┐          │
│  │ 柜01     │  │ 柜02     │  │ 柜03     │ ... │ 柜96     │          │
│  │ 传感器   │  │ 传感器   │  │ 传感器   │     │ 传感器   │          │
│  │ TCP Client│  │ TCP Client│  │ TCP Client│     │ TCP Client│          │
│  │ 本地缓存  │  │ 本地缓存  │  │ 本地缓存  │     │ 本地缓存  │          │
│  └────┬────┘  └────┬────┘  └────┬────┘     └────┬────┘          │
│       └────────────┬┴────────────┬┴──────────────┘                │
│                    ▼                                              │
│            ┌───────────────────┐                                  │
│            │  接入交换机（PoE） │                                  │
│            │  VLAN 100         │                                  │
│            └───────────────────┘                                  │
│                                                                     │
│  供电：每台配电柜内 PoE 交换机或 DC 24V 供电                        │
│  布线：Cat6 S/FTP，沿桥架敷设，与动力电缆隔离 ≥30cm                 │
└─────────────────────────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────────────────┐
│                    传感器固件架构                             │
│                                                             │
│  ┌────────────┐  ┌────────────┐  ┌───────────────────────┐ │
│  │ 采样任务    │→│ 数据缓存    │→│ TCP Client 上报任务    │ │
│  │ 2s 采集一次 │  │ Ring Buffer│  │ 长连接管理             │ │
│  │ 温湿度+I/O │  │ 容量: 128  │  │ 批量打包               │ │
│  └────────────┘  └────────────┘  │ 心跳/重连              │ │
│                                  └───────────────────────┘ │
│                                             │               │
│                                  ┌──────────┴────────────┐ │
│                                  │   TCP/IP 协议栈        │ │
│                                  │   LwIP + FreeRTOS     │ │
│                                  └────────────────────────┘ │
└─────────────────────────────────────────────────────────────┘

/* 配电柜温湿度传感器 - TCP Client 批量上报 */

#include "lwip/tcp.h"
#include "lwip/sockets.h"
#include "freertos/FreeRTOS.h"
#include "freertos/task.h"
#include "freertos/queue.h"
#include <string.h>

#define SERVER_IP       "192.168.100.200"
#define SERVER_PORT     5020
#define SAMPLE_INTERVAL 2000    // 2s 采样
#define REPORT_INTERVAL 30000   // 30s 上报
#define BUFFER_SIZE     128     // 本地缓存 128 组
#define KEEPALIVE_IDLE  30
#define KEEPALIVE_INTVL 5
#define KEEPALIVE_PROBES 3

/* 单组采样数据 */
typedef struct {
    uint32_t timestamp;     // 采样时间戳
    int16_t  temperature;  // 温度 ×10（如 256 = 25.6℃）
    int16_t  humidity;     // 湿度 ×10（如 523 = 52.3%RH）
    uint8_t  status;       // 状态字
    uint8_t  reserved;     // 保留
} __attribute__((packed)) SampleData;

/* 批量上报报文 */
typedef struct {
    uint16_t header;       // 帧头 0xAA55
    uint16_t length;       // 报文总长度
    uint32_t device_id;    // 设备 ID
    uint32_t sequence;     // 序列号
    uint32_t timestamp;    // 报文生成时间戳
    uint8_t  count;        // 数据点数量
    uint8_t  reserved[3];
    SampleData samples[0]; // 变长数组
} __attribute__((packed)) BatchReport;

static int g_sock = -1;
static bool g_connected = false;
static uint32_t g_sequence = 0;
static QueueHandle_t g_sample_queue = NULL;  // 采样数据队列
static SemaphoreHandle_t g_buffer_mutex = NULL;
static SampleData g_buffer[BUFFER_SIZE];
static uint16_t g_buffer_head = 0;
static uint16_t g_buffer_tail = 0;
static uint16_t g_buffer_count = 0;

/* 设置 TCP KeepAlive */
static void set_keepalive(int sockfd)
{
    int optval = 1;
    socklen_t optlen = sizeof(optval);
    setsockopt(sockfd, SOL_SOCKET, SO_KEEPALIVE, &optval, optlen);
    optval = KEEPALIVE_IDLE;
    setsockopt(sockfd, IPPROTO_TCP, TCP_KEEPIDLE, &optval, optlen);
    optval = KEEPALIVE_INTVL;
    setsockopt(sockfd, IPPROTO_TCP, TCP_KEEPINTVL, &optval, optlen);
    optval = KEEPALIVE_PROBES;
    setsockopt(sockfd, IPPROTO_TCP, TCP_KEEPCNT, &optval, optlen);
}

/* 连接到服务器 */
static int connect_to_server(void)
{
    struct sockaddr_in server_addr;
    int sock;

    sock = socket(AF_INET, SOCK_STREAM, 0);
    if (sock < 0) {
        LWIP_LOG("socket failed");
        return -1;
    }

    // 设置超时
    struct timeval tv = {3, 0};
    setsockopt(sock, SOL_SOCKET, SO_SNDTIMEO, &tv, sizeof(tv));
    setsockopt(sock, SOL_SOCKET, SO_RCVTIMEO, &tv, sizeof(tv));
    set_keepalive(sock);

    // 禁用 Nagle（小包实时性优先，但批量上报时启用）
    int nodelay = 0;  // 批量上报时启用 Nagle，减少小包
    setsockopt(sock, IPPROTO_TCP, TCP_NODELAY, &nodelay, sizeof(nodelay));

    memset(&server_addr, 0, sizeof(server_addr));
    server_addr.sin_family = AF_INET;
    server_addr.sin_port = htons(SERVER_PORT);
    server_addr.sin_addr.s_addr = inet_addr(SERVER_IP);

    if (connect(sock, (struct sockaddr *)&server_addr, sizeof(server_addr)) < 0) {
        close(sock);
        return -1;
    }

    g_sock = sock;
    g_connected = true;
    LWIP_LOG("connected to %s:%d", SERVER_IP, SERVER_PORT);
    return sock;
}

/* 采样任务 */
void sample_task(void *pvParameters)
{
    TickType_t last_wake = xTaskGetTickCount();

    while (1) {
        // 读取温湿度
        int16_t temp = read_temperature() * 10;  // ×10 存储
        int16_t hum = read_humidity() * 10;
        uint8_t status = get_status();

        SampleData sample = {
            .timestamp = get_timestamp(),
            .temperature = temp,
            .humidity = hum,
            .status = status,
            .reserved = 0
        };

        // 写入环形缓冲区
        xSemaphoreTake(g_buffer_mutex, portMAX_DELAY);
        g_buffer[g_buffer_head] = sample;
        g_buffer_head = (g_buffer_head + 1) % BUFFER_SIZE;
        if (g_buffer_count < BUFFER_SIZE) {
            g_buffer_count++;
        } else {
            // 缓冲区满，覆盖最旧数据
            g_buffer_tail = (g_buffer_tail + 1) % BUFFER_SIZE;
        }
        xSemaphoreGive(g_buffer_mutex);

        vTaskDelayUntil(&last_wake, pdMS_TO_TICKS(SAMPLE_INTERVAL));
    }
}

/* 构建批量上报报文 */
static int build_batch_report(uint8_t *buf, int buf_size)
{
    BatchReport *report = (BatchReport *)buf;

    xSemaphoreTake(g_buffer_mutex, portMAX_DELAY);

    // 确定本次上报的数据点数量
    uint8_t count = g_buffer_count;
    if (count > 15) count = 15;  // 最多 15 个点

    if (count == 0) {
        xSemaphoreGive(g_buffer_mutex);
        return 0;
    }

    // 填充报文头
    report->header = 0x55AA;
    report->length = sizeof(BatchReport) + count * sizeof(SampleData);
    report->device_id = get_device_id();
    report->sequence = ++g_sequence;
    report->timestamp = get_timestamp();
    report->count = count;
    report->reserved[0] = 0;
    report->reserved[1] = 0;
    report->reserved[2] = 0;

    // 复制数据
    for (int i = 0; i < count; i++) {
        report->samples[i] = g_buffer[g_buffer_tail];
        g_buffer_tail = (g_buffer_tail + 1) % BUFFER_SIZE;
        g_buffer_count--;
    }

    xSemaphoreGive(g_buffer_mutex);

    return report->length;
}

/* 上报任务 */
void report_task(void *pvParameters)
{
    uint8_t buffer[sizeof(BatchReport) + 15 * sizeof(SampleData) + 4];  // +4 for CRC
    TickType_t last_report = xTaskGetTickCount();

    // 初始连接
    while (connect_to_server() < 0) {
        LWIP_LOG("connect failed, retry in 5s");
        vTaskDelay(pdMS_TO_TICKS(5000));
    }

    while (1) {
        TickType_t now = xTaskGetTickCount();

        // 检查上报周期
        if (now - last_report >= pdMS_TO_TICKS(REPORT_INTERVAL)) {
            if (!g_connected) {
                // 重连
                static uint8_t retry = 0;
                uint32_t delay = 1000 * (1 << (retry > 6 ? 6 : retry));
                delay = delay * (0.7f + ((float)rand() / RAND_MAX) * 0.6f);
                retry++;
                vTaskDelay(pdMS_TO_TICKS(delay));
                connect_to_server();
                if (g_connected) retry = 0;
                continue;
            }

            // 构建并发送批量报文
            int len = build_batch_report(buffer, sizeof(buffer));
            if (len > 0) {
                // 计算 CRC
                uint16_t crc = calc_crc16(buffer, len);
                memcpy(buffer + len, &crc, 2);
                len += 2;

                if (send(g_sock, buffer, len, 0) < 0) {
                    LWIP_LOG("send failed, errno=%d", errno);
                    g_connected = false;
                    close(g_sock);
                    g_sock = -1;
                }
            }

            last_report = now;
        }

        // 心跳（每 30s）
        static TickType_t last_heartbeat = 0;
        if (now - last_heartbeat >= pdMS_TO_TICKS(30000)) {
            if (g_connected) {
                uint8_t hb[8] = {0xAA, 0x55, 0x00, 0x08, 0x00, 0x00, 0x00, 0x00};
                // 填充设备 ID 和序列号
                memcpy(hb + 2, &g_device_id, 4);
                memcpy(hb + 6, &g_sequence, 2);
                send(g_sock, hb, 8, 0);
            }
            last_heartbeat = now;
        }

        vTaskDelay(pdMS_TO_TICKS(1000));
    }
}

/* 主入口 */
void app_main(void)
{
    g_sample_queue = xQueueCreate(32, sizeof(SampleData));
    g_buffer_mutex = xSemaphoreCreateMutex();

    xTaskCreate(sample_task, "sample", 2048, NULL, 4, NULL);
    xTaskCreate(report_task, "report", 4096, NULL, 3, NULL);
}

import asyncio
import struct
import time
from typing import Dict, List, Optional, Tuple
from dataclasses import dataclass, field
from datetime import datetime
import logging

logging.basicConfig(level=logging.INFO, format='%(asctime)s [%(levelname)s] %(message)s')
logger = logging.getLogger(__name__)

@dataclass
class SensorSession:
    """传感器会话"""
    device_id: int
    reader: asyncio.StreamReader
    writer: asyncio.StreamWriter
    cabinet_id: str = ""        # 配电柜编号
    location: str = ""          # 位置描述
    connected_time: float = 0.0
    last_heartbeat: float = 0.0
    last_report: float = 0.0
    total_reports: int = 0
    total_samples: int = 0
    total_bytes: int = 0
    sequence: int = 0
    last_seq: int = 0
    packet_loss: int = 0
    status: str = "CONNECTED"
    buffer: List[Dict] = field(default_factory=list)  # 数据缓冲

@dataclass
class SampleData:
    timestamp: int
    temperature: float
    humidity: float
    status: int

class PowerCabinetServer:
    """配电柜集群监测服务器"""

    def __init__(self, host: str = "0.0.0.0", port: int = 5020,
                 max_connections: int = 512,
                 heartbeat_timeout: float = 90.0,
                 data_callback=None,
                 alarm_callback=None):
        self.host = host
        self.port = port
        self.max_connections = max_connections
        self.heartbeat_timeout = heartbeat_timeout
        self.data_callback = data_callback
        self.alarm_callback = alarm_callback
        self.sessions: Dict[int, SensorSession] = {}
        self.cabinet_map: Dict[str, int] = {}  # cabinet_id -> device_id
        self.running = False

    async def _handle_client(self, reader: asyncio.StreamReader,
                             writer: asyncio.StreamWriter):
        """处理单个客户端连接"""
        peer = writer.get_extra_info('peername')
        device_id = None

        try:
            # 握手：等待设备注册
            # 第一个报文应为注册报文（或直接在批量报文中解析 device_id）
            data = await asyncio.wait_for(reader.read(1024), timeout=10.0)
            if len(data) < 12:
                logger.warning(f"Invalid handshake from {peer}")
                writer.close()
                return

            # 解析注册信息（简化：从第一个批量报文中获取 device_id）
            if data[0] == 0xAA and data[1] == 0x55:
                device_id = struct.unpack_from('<I', data, 4)[0]
            else:
                logger.warning(f"Unknown packet from {peer}")
                writer.close()
                return

            # 创建会话
            if device_id in self.sessions:
                # 设备重连，关闭旧连接
                old = self.sessions[device_id]
                logger.info(f"Device {device_id} reconnected, closing old session")
                try:
                    old.writer.close()
                except:
                    pass

            session = SensorSession(
                device_id=device_id,
                reader=reader,
                writer=writer,
                connected_time=time.time(),
                last_heartbeat=time.time(),
                last_report=time.time()
            )
            self.sessions[device_id] = session
            logger.info(f"Device {device_id} connected from {peer}, "
                       f"total sessions: {len(self.sessions)}")

            # 持续读取数据
            await self._read_loop(session)

        except asyncio.TimeoutError:
            logger.warning(f"Handshake timeout from {peer}")
        except (ConnectionResetError, BrokenPipeError) as e:
            logger.info(f"Device {device_id} disconnected: {e}")
        except Exception as e:
            logger.error(f"Session error for device {device_id}: {e}")
        finally:
            if device_id and device_id in self.sessions:
                session = self.sessions[device_id]
                session.status = "DISCONNECTED"
                # 保留会话信息但关闭连接
                try:
                    writer.close()
                    await writer.wait_closed()
                except:
                    pass
                logger.info(f"Device {device_id} session closed, "
                           f"total reports: {session.total_reports}, "
                           f"total samples: {session.total_samples}")

    async def _read_loop(self, session: SensorSession):
        """读取循环"""
        while True:
            # 读取报文头（至少 16 字节）
            header = await reader_read_exact(session.reader, 16)
            if not header:
                break

            if header[0] != 0xAA or header[1] != 0x55:
                logger.warning(f"Device {session.device_id}: invalid header "
                              f"{header[0]:02x}{header[1]:02x}")
                continue

            # 解析报文头
            length, device_id, sequence, timestamp, count = \
                struct.unpack_from('<HIHIB', header, 2)

            # 读取剩余数据
            remaining = length - 16
            if remaining < 0 or remaining > 1024:
                logger.warning(f"Device {session.device_id}: invalid length {length}")
                break

            payload = await reader_read_exact(session.reader, remaining)
            if not payload:
                break

            # 更新会话信息
            session.last_report = time.time()
            session.sequence = sequence
            session.total_reports += 1

            # 解析数据
            await self._parse_batch_report(session, timestamp, count, payload)

    async def _parse_batch_report(self, session: SensorSession,
                                   timestamp: int, count: int,
                                   payload: bytes):
        """解析批量上报报文"""
        offset = 0
        samples = []

        for i in range(count):
            if offset + 8 > len(payload):
                break

            ts, temp_raw, hum_raw, status = struct.unpack_from(
                '<IhhBB', payload, offset
            )
            offset += 8

            sample = {
                'device_id': session.device_id,
                'cabinet_id': session.cabinet_id,
                'location': session.location,
                'timestamp': ts,
                'temperature': temp_raw * 0.1,
                'humidity': hum_raw * 0.1,
                'status': status,
                'received_at': time.time()
            }
            samples.append(sample)
            session.total_samples += 1

        # 数据回调
        if self.data_callback:
            await self.data_callback(samples)

        # 告警检测
        for s in samples:
            if self.alarm_callback:
                await self.alarm_callback(s)

        # 心跳更新
        session.last_heartbeat = time.time()

        # 序列号连续性检查
        if session.last_seq > 0:
            expected = (session.last_seq + 1) & 0xFFFFFFFF
            if sequence != expected:
                loss = (sequence - expected) & 0xFFFFFFFF
                if loss < 100:  # 防止回绕误判
                    session.packet_loss += loss
                    logger.debug(f"Device {session.device_id}: "
                               f"seq jump {session.last_seq} -> {sequence}, "
                               f"loss={loss}")
        session.last_seq = sequence

    async def _heartbeat_monitor(self):
        """心跳监控任务"""
        while self.running:
            await asyncio.sleep(10)
            now = time.time()
            disconnected = []

            for device_id, session in self.sessions.items():
                if session.status == "CONNECTED":
                    idle_time = now - session.last_heartbeat
                    if idle_time > self.heartbeat_timeout:
                        logger.warning(
                            f"Device {device_id} heartbeat timeout "
                            f"({idle_time:.0f}s), closing"
                        )
                        disconnected.append(device_id)
                        try:
                            session.writer.close()
                        except:
                            pass

            for did in disconnected:
                if did in self.sessions:
                    self.sessions[did].status = "TIMEOUT"

    async def _stats_reporter(self):
        """统计报告"""
        while self.running:
            await asyncio.sleep(60)
            connected = sum(1 for s in self.sessions.values()
                          if s.status == "CONNECTED")
            total_samples = sum(s.total_samples for s in self.sessions.values())
            total_reports = sum(s.total_reports for s in self.sessions.values())
            total_loss = sum(s.packet_loss for s in self.sessions.values())

            logger.info(
                f"[STATS] Connected: {connected}/{len(self.sessions)} | "
                f"Reports: {total_reports} | Samples: {total_samples} | "
                f"Packet Loss: {total_loss}"
            )

    async def start(self):
        """启动服务器"""
        self.running = True

        # 启动心跳监控
        asyncio.create_task(self._heartbeat_monitor())
        # 启动统计报告
        asyncio.create_task(self._stats_reporter())

        server = await asyncio.start_server(
            self._handle_client, self.host, self.port
        )

        addrs = ', '.join(str(sock.getsockname()) for sock in server.sockets)
        logger.info(f"Power Cabinet Server listening on {addrs}, "
                   f"max connections: {self.max_connections}")

        async with server:
            await server.serve_forever()

    def get_status(self) -> Dict:
        """获取所有会话状态"""
        status = {}
        for did, session in self.sessions.items():
            status[did] = {
                'cabinet_id': session.cabinet_id,
                'location': session.location,
                'status': session.status,
                'connected_time': session.connected_time,
                'last_heartbeat': session.last_heartbeat,
                'total_reports': session.total_reports,
                'total_samples': session.total_samples,
                'packet_loss': session.packet_loss,
                'idle_time': time.time() - session.last_heartbeat
            }
        return status

    def stop(self):
        self.running = False


async def reader_read_exact(reader: asyncio.StreamReader, n: int) -> Optional[bytes]:
    """精确读取 n 字节"""
    try:
        return await reader.readexactly(n)
    except (asyncio.IncompleteReadError, ConnectionError):
        return None


# 数据回调示例
async def on_data(samples: List[Dict]):
    """数据接收回调"""
    for s in samples:
        print(f"[{datetime.fromtimestamp(s['timestamp'])}] "
              f"柜{s['cabinet_id']} T={s['temperature']:.1f}℃ "
              f"H={s['humidity']:.1f}%RH")

async def on_alarm(sample: Dict):
    """告警回调"""
    if sample['status'] & 0x01:  # 高温告警
        print(f"⚠️  ALARM: 柜{sample['cabinet_id']} 高温 "
              f"{sample['temperature']:.1f}℃")
    if sample['status'] & 0x04:  # 高湿告警
        print(f"⚠️  ALARM: 柜{sample['cabinet_id']} 高湿 "
              f"{sample['humidity']:.1f}%RH")


# 主程序
async def main():
    server = PowerCabinetServer(
        host="0.0.0.0",
        port=5020,
        max_connections=512,
        heartbeat_timeout=90.0,
        data_callback=on_data,
        alarm_callback=on_alarm
    )

    # 配置配电柜映射
    server.cabinet_map = {
        "PS-01": 1001, "PS-02": 1002, "PS-03": 1003,
        # ...
    }

    try:
        await server.start()
    except KeyboardInterrupt:
        server.stop()
        print("Server stopped")


if __name__ == "__main__":
    asyncio.run(main())

┌────────────────────────────────────────────────────────────────┐
│                    批量上报报文格式                             │
├──────────┬──────┬──────────┬──────────┬─────────┬─────┬───────┤
│ 帧头     │ 长度 │ 设备 ID  │ 序列号   │ 时间戳  │ 数量│ 保留  │
│ 2B       │ 2B   │ 4B       │ 4B       │ 4B      │ 1B  │ 3B    │
│ 0xAA55   │ N    │ uint32   │ uint32   │ uint32  │ u8  │ -     │
├──────────┴──────┴──────────┴──────────┴─────────┴─────┴───────┤
│                    数据点（变长）                               │
├──────────┬──────────┬──────────┬───────────────────────────────┤
│ 时间戳   │ 温度     │ 湿度     │ 状态                           │
│ 4B       │ 2B(int16)│ 2B(int16)│ 1B                             │
│ uint32   │ ×0.1℃   │ ×0.1%RH  │ bit0:高温 bit1:低温 bit2:高湿  │
│          │          │          │ bit3:低湿 bit4:传感器故障       │
├──────────┼──────────┼──────────┼───────────────────────────────┤
│ ...      │ ...      │ ...      │ ...                           │
├──────────┴──────────┴──────────┴───────────────────────────────┤
│ CRC16 (2B)                                                     │
└────────────────────────────────────────────────────────────────┘

示例（1 个数据点）：
  AA 55 1A 00 00 00 03 E9 01 00 00 00 5E 8A A2 60
  01 3E 8F 00 02 0D 00 00 00 00 00 00 00 00 00 00
  01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  XX XX

  → 长度 0x001A = 26 字节
  → 设备 ID 0x000003E9 = 1001
  → 序列号 0x00000001
  → 时间戳 0x60A28A5E
  → 数量 1
  → 数据点：时间戳 3E8F0000(小端) = 0x00008F3E, 温度 0100(小端)=0x0001,
           湿度 0D00(小端)=0x000D, 状态 00
  → CRC16

┌──────────┬──────────┬──────────┐
│ 帧头     │ 设备 ID  │ 序列号   │
│ 2B       │ 4B       │ 2B       │
│ 0xAA55   │ uint32   │ uint16   │
└──────────┴──────────┴──────────┘

无 CRC，无长度字段（固定 8 字节）
用于保持连接活跃，防止中间设备/NAT 超时断开

方案 A：每台柜内独立 PoE 交换机
  优点：每台柜独立供电、独立网络，单点故障不扩散
  缺点：柜内设备多（不止温湿度传感器），成本高

方案 B：区域汇聚 + 长线
  优点：成本最低
  缺点：超 100m 需中继，故障面大

方案 C：柜内微型 PoE 交换机（推荐）
  每台配电柜内装一台 5-8 口工业 PoE 交换机
  传感器 + 智能断路器 + 局放传感器 共用
  上行汇聚到配电室接入交换机

  成本与可靠性平衡最好

接入交换机端口配置：
  → 端口安全：MAC 限制 1-2 个（柜内只有 1-2 台网络设备）
  → BPDU Guard：启用
  → Storm Control：广播抑制 5%
  → PoE 优先级：Critical（温湿度监测是安全相关）
  → IGMP Snooping：如果后续加视频巡检
  → Port Fast：启用（接入端口直接转发）

汇聚交换机：
  → VLAN 隔离：监测 VLAN 独立
  → DHCP Snooping：防止私接 DHCP
  → DAI（动态 ARP 检测）：防止 ARP 欺骗
  → ACL：只允许监测 VLAN 到采集服务器 5020 端口

并发 96 台传感器：
  CPU：2 核（asyncio 单线程即可处理）
  内存：512MB（每个会话约 2-4KB）
  网络：10Mbps（绰绰有余）
  文件描述符：至少 512（96 连接 + 系统预留）

并发 500+ 台：
  CPU：4-8 核
  内存：2-4GB
  网络：100Mbps
  文件描述criptor：2048+
  建议分片部署（按配电室分区）

from influxdb_client import InfluxDBClient, Point, WriteOptions
from influxdb_client.client.write_api import SYNCHRONOUS

class DataWriter:
    def __init__(self, url, token, org, bucket):
        self.client = InfluxDBClient(url=url, token=token, org=org)
        self.write_api = self.client.write_api(write_options=SYNCHRONOUS)
        self.bucket = bucket
        self.org = org

    async def write_batch(self, samples: List[Dict]):
        """批量写入"""
        points = []
        for s in samples:
            point = Point("power_cabinet_temp_hum") \
                .tag("device_id", str(s['device_id'])) \
                .tag("cabinet_id", s['cabinet_id']) \
                .tag("location", s['location']) \
                .field("temperature", s['temperature']) \
                .field("humidity", s['humidity']) \
                .field("status", s['status']) \
                .time(datetime.fromtimestamp(s['timestamp']))
            points.append(point)

        # 批量写入
        self.write_api.write(bucket=self.bucket, org=self.org, record=points)

ALARM_RULES = {
    'high_temp': {
        'threshold': 45.0,        # ℃
        'duration': 300,         # 连续 5 分钟
        'severity': 'CRITICAL',
        'action': ['sound_alarm', 'send_sms', 'trigger_ac']
    },
    'high_humidity': {
        'threshold': 80.0,       # %RH
        'duration': 600,         # 连续 10 分钟
        'severity': 'WARNING',
        'action': ['send_sms', 'start_dehumidifier']
    },
    'sensor_offline': {
        'threshold': 90,         # 秒（心跳超时）
        'duration': 0,
        'severity': 'WARNING',
        'action': ['send_sms']
    }
}

class AlarmEngine:
    def __init__(self, rules: Dict):
        self.rules = rules
        self.state = {}  # 持续时长跟踪

    async def check(self, sample: Dict):
        device_id = sample['device_id']

        # 温度告警
        if sample['temperature'] > self.rules['high_temp']['threshold']:
            self._increment(device_id, 'high_temp')
            if self.state[device_id]['high_temp'] >= self.rules['high_temp']['duration']:
                await self._trigger_alarm('high_temp', sample)
        else:
            self._reset(device_id, 'high_temp')

        # 湿度告警
        if sample['humidity'] > self.rules['high_humidity']['threshold']:
            self._increment(device_id, 'high_humidity')
            if self.state[device_id]['high_humidity'] >= self.rules['high_humidity']['duration']:
                await self._trigger_alarm('high_humidity', sample)
        else:
            self._reset(device_id, 'high_humidity')
