问如何从WKT多边形计算IOU分数？

EN

import pandas as pd
import csv
import shapely
import shapely.wkt as wkt
from shapely.geometry import MultiPolygon
import shapely.ops as so
import shapely.geometry as sg
import shapely.ops as so
import matplotlib.pyplot as plt

def polt_image(mul_poly_shape):
    if isinstance(mul_poly_shape, list):
        image_plot = MultiPolygon(map(wkt.loads, mul_poly_shape))
    else:
        image_plot = mul_poly_shape
    fig, axs = plt.subplots()
    axs.set_aspect('equal', 'datalim')
    for geom in image_plot.geoms:
        xs, ys = geom.exterior.xy
        axs.fill(xs, ys, alpha=0.5, fc='r', ec='none')
    #plt.show()


csv_file_experiment = '/home/salman/Downloads/data/spacenet6/LGBM_CSVs/exp_0009_0_2.csv'
csv_file_gts = '/home/salman/Downloads/data/spacenet6/val_polygons/ground_truths.csv'


col1 = ["ImageId", "PolygonWKT_Pix","BuildingId"]
exp_data = pd.read_csv(csv_file_experiment, usecols=col1)


col2 = ["ImageId","PolygonWKT_Pix","TileBuildingId"]
gts_data = pd.read_csv(csv_file_gts, usecols=col2)
unique_gts_imageIDs = pd.unique(gts_data[['ImageId']].values.ravel())
#print("unique_gts_imageIDs: ",unique_gts_imageIDs)
count = 0
for i in unique_gts_imageIDs:
    count =  count + 1
print("count", count)

gts_inner_loop_count = 0
results1 = pd.read_csv(csv_file_gts)
gts_inner_loop_count = len(results1)
gts_inner_loop_count =  gts_inner_loop_count + 1

inner_loop_count = 0
results = pd.read_csv(csv_file_experiment)
inner_loop_count = len(results)
inner_loop_count =  inner_loop_count + 1
average_accuracy = 0.0
average_accuracy_sum = 0.0
wl = 0
match_count = 0
while wl < count:
    print("Unique Image ID: ",unique_gts_imageIDs[wl])
    print("outer loop: ",wl)
    gts_tile = []
    exp_tile = []
    k = 0
    while k <= gts_inner_loop_count:
        #print("unique_gts_imageIDs['ImageId'].get(wl) : ", unique_gts_imageIDs[wl])
        unique_Image_ID = unique_gts_imageIDs[wl]
        gts_data_Image_ID = gts_data['ImageId'].get(k)
        #print("gts_data['ImageId'].get(wl) : ", gts_data['ImageId'].get(wl))
        if unique_Image_ID == gts_data_Image_ID:
            #print("Matched")
            print("gts_data_Image_ID: ", gts_data_Image_ID)
            print("gts_data_Building_ID: ", gts_data['TileBuildingId'].get(k))
            match_count = match_count + 1
            #print("Match Count: ", match_count)
            PolygonWKT_Pix = str(gts_data['PolygonWKT_Pix'].get(k))
            #print("gts_PolygonWKT_Pix: ",PolygonWKT_Pix)
            if PolygonWKT_Pix != None and PolygonWKT_Pix != "":
                gts_tile.append(PolygonWKT_Pix)
            #gts_tile = gts_tile.append(f"{PolygonWKT_Pix}")
        k  = k + 1
    gts_img = MultiPolygon(map(wkt.loads, gts_tile))
    print ("gts_img: ",gts_img)

    t = 0
    while t <= inner_loop_count:
        #print("unique_gts_imageIDs['ImageId'].get(wl) : ", unique_gts_imageIDs[wl])
        unique_Image_ID = unique_gts_imageIDs[wl]
        exp_data_Image_ID = exp_data['ImageId'].get(t)

        #print("gts_data['ImageId'].get(wl) : ", gts_data['ImageId'].get(wl))
        if unique_Image_ID == exp_data_Image_ID:
            #print("unique_Image_ID: ", unique_Image_ID)
            print("exp_data_Image_ID: ", exp_data_Image_ID)
            print("exp_data_Building_ID: ",exp_data['BuildingId'].get(t))
            #print("Matched")
            match_count = match_count + 1
            #print("Match Count: ", match_count)
            exp_PolygonWKT_Pix = str(exp_data['PolygonWKT_Pix'].get(t))
            #print("\nexp_PolygonWKT_Pix: ",exp_PolygonWKT_Pix)
            #if exp_PolygonWKT_Pix == 'POLYGON EMPTY':
            #    exp_PolygonWKT_Pix = 0
            #    exp_PolygonWKT_Pix = str(exp_PolygonWKT_Pix)
            if exp_PolygonWKT_Pix != None and exp_PolygonWKT_Pix != "":
                exp_tile.append(exp_PolygonWKT_Pix)
            #gts_tile = gts_tile.append(f"{PolygonWKT_Pix}")
        t  = t + 1
    #print("gts_tile: ",gts_tile)
    #print("exp_tile: ",exp_tile)
    exp_img = MultiPolygon(map(wkt.loads, exp_tile))
    print("exp_img: ",exp_img)


    intersection = gts_img.intersection(exp_img)
    union = gts_img.union(exp_img)

    #print("intersection: ", intersection)
    #print("union: ", union)

    #polt_image(gts_tile)
    #polt_image(exp_tile)
    #polt_image(intersection)
    #polt_image(union)
    print(intersection.area)
    if intersection.area == 0.0 and union.area == 0.0:
            image_accuracy = 0.0
    else:
        image_accuracy = intersection.area / union.area
    print("\nimage_accuracy: " , image_accuracy)
    average_accuracy_sum = average_accuracy_sum + image_accuracy
    print("average_accuracy_sum", average_accuracy_sum)
    wl = wl + 1



average_accuracy = average_accuracy_sum / count
print("average_accuracy: ", average_accuracy)
