无法在nginx反向代理后面访问Minio控制台
无法在nginx反向代理后面访问Minio控制台
提问于 2022-04-26 21:49:31
我正在尝试将一个example.com/minio位置重定向到minio控制台，该控制台运行在一个nginx代理之后，这两个代理都是由一个坞编写文件运行的。我的问题是，当我试图将minio端点反向代理到路径(如/minio )时，它不起作用，但是当我在nginx反向代理中的根路径上运行minio反向代理时，它就工作了。我真的找不出问题出在哪里。
这是我的撰写文件：
services:
nginx:
container_name: nginx
image: nginx
restart: unless-stopped
ports:
- 80:80
- 443:443
volumes:
- ./nginx.conf:/etc/nginx/conf.d/default.conf
- ./log/nginx:/var/log/nginx/
minio:
image: minio/minio
container_name: minio
volumes:
- ./data/minio/:/data
command: server /data --address ':9000' --console-address ':9001'
environment:
MINIO_ROOT_USER: minio_admin
MINIO_ROOT_PASSWORD: minio_123456
ports:
- 9000
- 9001
restart: always
logging:
driver: "json-file"
options:
max-file: "10"
max-size: 20m
healthcheck:
test: ["CMD", "curl", "-f", "http://127.0.0.1:9000/minio/health/live"]
interval: 30s
timeout: 20s
retries: 3我的nginx配置如下：
server {
listen 80;
server_name example.com;
# To allow special characters in headers
ignore_invalid_headers off;
# Allow any size file to be uploaded.
# Set to a value such as 1000m; to restrict file size to a specific value
client_max_body_size 0;
# To disable buffering
proxy_buffering off;
access_log /var/log/nginx/service-access.log;
error_log /var/log/nginx/service-error.log debug;
location / {
return 200 "salam";
default_type text/plain;
}
location /minio {
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
proxy_set_header Host $http_host;
proxy_connect_timeout 300;
# Default is HTTP/1, keepalive is only enabled in HTTP/1.1
proxy_http_version 1.1;
proxy_set_header Connection "";
chunked_transfer_encoding off;
proxy_pass http://minio:9001;
}
}我在域上看到的minio控制台图片如下：
以及卷曲端点($ curl -k http://example.com/minio)的响应：
<null>
<html lang="en">
<head>
<meta charset="utf-8" />
<base href="/" />
<meta content="width=device-width,initial-scale=1" name="viewport" />
<meta content="#081C42" media="(prefers-color-scheme: light)" name="theme-color" />
<meta content="#081C42" media="(prefers-color-scheme: dark)" name="theme-color" />
<meta content="MinIO Console" name="description" />
<link href="./styles/root-styles.css" rel="stylesheet" />
<link href="./apple-icon-180x180.png" rel="apple-touch-icon" sizes="180x180" />
<link href="./favicon-32x32.png" rel="icon" sizes="32x32" type="image/png" />
<link href="./favicon-96x96.png" rel="icon" sizes="96x96" type="image/png" />
<link href="./favicon-16x16.png" rel="icon" sizes="16x16" type="image/png" />
<link href="./manifest.json" rel="manifest" />
<link color="#3a4e54" href="./safari-pinned-tab.svg" rel="mask-icon" />
<title>MinIO Console</title>
<script defer="defer" src="./static/js/main.eec275cb.js"></script>
<link href="./static/css/main.90d417ae.css" rel="stylesheet">
</head>
<body>
<noscript>You need to enable JavaScript to run this app.</noscript>
<div id="root">
<div id="preload">
<img src="./images/background.svg" />
<img src="./images/background-wave-orig2.svg" />
</div>
<div id="loader-block">
<img src="./Loader.svg" />
</div>
</div>
</body>
</html>
%回答 2
Stack Overflow用户
回答已采纳
发布于 2022-04-27 12:48:55
minio在非默认路径(如location /minio )下不工作
你需要使用位置/{.proxy_pass http://localhost:9001；}或向nginx添加另一个具有子域的服务器块，如下所示
server{
listen 80;
server_name minio.example.com;;
location / {
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
proxy_set_header Host $http_host;
proxy_pass http://localhost:9001;
}
}Stack Overflow用户
发布于 2022-06-10 09:37:31
https://github.com/arschles/minio-howto/blob/master/setup-Nginx-proxy-with-Minio-Server.md
如果使用nginx容器，则将该文件添加到/etc/nginx/conf.d .d中，并删除同一目录中现有的default.conf文件。
