DJI SDK -在圆形轨道上飞行,设置半径(米/英尺)和热点任务的空气2S
EN

Stack Overflow用户
提问于 2022-05-22 11:19:15
回答 1查看 73关注 0票数 0

我正试图把无人驾驶飞机绕着车绕着圆形轨道飞行,停在地面上。如果无人机最初是垂直于前左轮胎的固定距离的话,它是绕着汽车的圆周方向(顺时针方向)飞行的。但是,当无人机被放置在汽车的右侧或左侧时,无人机从放置点开始以圆形轨道飞行,离车太远,而不是像Pic 2所示的那样绕车飞行。

图1-

图2-

这是我的密码:

代码语言:javascript
运行
复制
var flightController: DJIFlightController?
var timer: Timer?
var radians: Float = 0.0
let velocity: Float = 0.1

@IBAction func actionOrbit(_ sender: Any) {
    setupFlightMode()
        // Schedule the timer at 2Hz while the default specified for DJI is between 5 and 25Hz
        timer = Timer.scheduledTimer(timeInterval: 0.5, target: self, selector: #selector(timerLoop), userInfo: nil, repeats: true)
}

private func setupFlightMode() {
    // Reset radians
    radians = 0.0
    // Invalidate timer if necessary
    // This allows switching between flight modes
    if timer != nil {
       print("invalidating")
       timer?.invalidate()
    }
 }

 @objc func timerLoop() {
    radians += velocity
    if(radians >= 6.283){ //360 degree it will stop the drone once the one orbit is complete
       self.timer?.invalidate()
       radians = 0.0
       self.verticalMoveUpward()
       //vertical throttle and then move forward and land
       return
    }
    x = cos(radians)
    y = sin(radians)
    z = 0
 }

 private func sendControlData(x: Float, y: Float, z: Float) {
    print("Sending x: \(x), y: \(y), z: \(z), yaw: \(yaw)")
    // Construct the flight control data object
    var controlData = DJIVirtualStickFlightControlData()
    controlData.verticalThrottle = z //throttle // in m/s
    controlData.roll = x //roll
    controlData.pitch = y //pitch
    controlData.yaw = self.yaw

    // Send the control data to the FC
    self.flightController?.send(controlData, withCompletion: { (error: Error?) in
        // There's an error so let's stop
        if error != nil {
            print("Error sending data")
            // Disable the timer
            self.timer?.invalidate()
        }
        else{
            print("Error sending data \(error.debugDescription)")
        }
    })
}

使用的无人机模型: Air 2S

问题1:无论无人机的位置如何,我怎样才能让无人机绕着汽车在圆形轨道上飞行?

问题2:如何确定圆轨道的半径(以米或英尺为单位)?目前,每0.5秒,它继续增加半径0.1,直到达到6.283。是否与评论中提到的频率,即2Hz有关。

问题3:根据文档,有一个热点任务,可以识别和设置对象。然后无人机就可以绕着它飞行。无人机模型是否有可能:空气2S,如果是,我如何提供半径(米),而不是纬度和经度。

EN

回答 1

Stack Overflow用户

发布于 2022-05-28 21:40:08

如果我理解,你纠正你试图改变滚动和音高作为一个函数的时间?它永远不会起作用。你必须检查无人机的位置,并让pid调节器调整错误,为你想要的路径。gps-pos由gps和imu融合而成.如果您没有gps,则只使用imu (也许是传感器),从起飞点开始使用lat/lon=0。您还将在risc中获得dji令人毛骨悚然的万向节运动,因为这是他们实现虚拟棒的一个缺陷。没什么可做的。

票数 0
EN
页面原文内容由Stack Overflow提供。腾讯云小微IT领域专用引擎提供翻译支持
原文链接:

https://stackoverflow.com/questions/72337087
