问如何在D3.js中用模式将图表保存/导出到.svg文件？

EN

var btn = document.getElementById("btn");
var rotateRect = document.getElementById("rotateRect");
  var data = [{ year: '2001', value:10 },
            { year: '2002', value:30 },
            { year: '2003', value:20 },
           ]
var svg = d3.select("svg#barchart"),
            margin = 200,
            width = svg.attr("width") - margin,
            height = svg.attr("height") - margin


var xScale = d3.scaleBand().range([0, width]).padding(0.4),
            yScale = d3.scaleLinear().range([height, 0]);

var g = svg.append("g")
            .attr("transform", "translate(" + 100 + "," + 100 + ")");



        xScale.domain(data.map(function(d) { return d.year; }));
        yScale.domain([0, d3.max(data, function(d) { return d.value; })]);

        g.append("g")
         .attr("transform", "translate(0," + height + ")")
         .call(d3.axisBottom(xScale));

        g.append("g")
         .call(d3.axisLeft(yScale).tickFormat(function(d){
             return d;
         }).ticks(10));

        g.selectAll(".bar")
         .data(data)
         .enter().append("rect")
         .attr("class", "bar")
         .attr("x", function(d) { return xScale(d.year); })
         .attr("y", function(d) { return yScale(d.value); })
         .attr("width", xScale.bandwidth())
         .attr("height", function(d) { return height - yScale(d.value); })
         .attr('stroke', "black")
         .attr('stroke-width', '1')
         // .attr("fill", "white")
         .attr("fill", function(d,i) { return  "url(#pattern" + (i+1) +")"});

btn.onclick = function(){
  console.log("save svg")
  var svgData = $("#barchart")[0].outerHTML;
var svgBlob = new Blob([svgData], {type:"image/svg+xml;charset=utf-8"});
var svgUrl = URL.createObjectURL(svgBlob);
var downloadLink = document.createElement("a");
downloadLink.href = svgUrl;
downloadLink.download = "new.svg";
document.body.appendChild(downloadLink);
downloadLink.click();
document.body.removeChild(downloadLink);
}

#rotateRect{
  transform:rotate(45deg);
    transform-origin: center center;
    transform-box: fill-box;
}

<script src="https://d3js.org/d3.v4.min.js"></script>
<script src="https://cdn.staticfile.org/jquery/1.10.2/jquery.min.js">
</script>

<svg id = "barchart" width="600" height="500"></svg>

<svg width="0" height="0">

    <defs>
        <pattern id="pattern1"
                 x="0" y="0" width="20" height="20"
                 patternUnits="userSpaceOnUse" >

<!--             <circle cx="10" cy="10" r="10" style="stroke: none; fill: #0000ff" /> -->
          <rect id="rotateRect" x="5" y = "5" width = "10" height = "10" />

        </pattern>
      </defs>

      <defs>
        <pattern id="pattern2"
                 x="0" y="0" width="20" height="20"
                 patternUnits="userSpaceOnUse" >

            <circle cx="10" cy="10" r="5" style="stroke: none; fill: #0000ff" />

        </pattern>
      </defs>

      <defs>
        <pattern id="pattern3"
                 x="0" y="0" width="20" height="20"
                 patternUnits="userSpaceOnUse" >

            <circle cx="10" cy="10" r="3" style="stroke: none; fill: #0000ff" />

        </pattern>
      </defs>

</svg>

<button id="btn">Save SVG</button>
