问LiveCharts WPF对实时数据的处理速度较慢。提高LiveCharts实时绘图性能

EN

public class DataModel : INotifyPropertyChanged
{
  public DataModel()
  {
    this.ChartValues = new ChartValues<ObservablePoint>();
    this.XMax = 360;
    this.XMin = 0;

    // Initialize the sine graph
    for (double x = this.XMin; x <= this.XMax; x++)
    {
      var point = new ObservablePoint()
      {
        X = x,
        Y = Math.Sin(x * Math.PI / 180)
      };
      this.ChartValues.Add(point);
    }

    // Setup the data mapper
    this.DataMapper = new CartesianMapper<ObservablePoint>()
      .X(point => point.X)
      .Y(point => point.Y)
      .Stroke(point => point.Y > 0.3 ? Brushes.Red : Brushes.LightGreen)
      .Fill(point => point.Y > 0.3 ? Brushes.Red : Brushes.LightGreen);

    // Setup the IProgress<T> instance in order to update the chart (UI thread)
    // from the background thread
    var progressReporter = new Progress<double>(newValue => ShiftValuesToTheLeft(newValue, CancellationToken.None));

    // Generate the new data points on a background thread
    // and use the IProgress<T> instance to update the chart on the UI thread
    Task.Run(async () => await StartSineGenerator(progressReporter, CancellationToken.None));
  }

  // Dynamically add new data
  private void ShiftValuesToTheLeft(double newValue, CancellationToken cancellationToken)
  {
    // Shift item data (and not the items) to the left
    for (var index = 0; index < this.ChartValues.Count - 1; index++)
    {
      cancellationToken.ThrowIfCancellationRequested();

      ObservablePoint currentPoint = this.ChartValues[index];
      ObservablePoint nextPoint = this.ChartValues[index + 1];
      currentPoint.X = nextPoint.X;
      currentPoint.Y = nextPoint.Y;
    }

    // Add the new reading
    ObservablePoint newPoint = this.ChartValues[this.ChartValues.Count - 1];
    newPoint.X = newValue;
    newPoint.Y = Math.Sin(newValue * Math.PI / 180);

    // Update axis min/max
    this.XMax = newValue;
    this.XMin = this.ChartValues[0].X;
  }

  private async Task StartSineGenerator(IProgress<double> progressReporter, CancellationToken cancellationToken)
  {
    while (true)
    {
      // Add the new reading by posting the callback to the UI thread
      ObservablePoint newPoint = this.ChartValues[this.ChartValues.Count - 1];
      double newXValue = newPoint.X + 1;
      progressReporter.Report(newXValue);

      // Check if CancellationToken.Cancel() was called
      cancellationToken.ThrowIfCancellationRequested();

      // Plot at 1/10ms
      await Task.Delay(TimeSpan.FromMilliseconds(10), cancellationToken);
    }
  }

  private double xMax;
  public double XMax
  {
    get => this.xMax;
    set
    {
      this.xMax = value;
      OnPropertyChanged();
    }
  }

  private double xMin;
  public double XMin
  {
    get => this.xMin;
    set
    {
      this.xMin = value;
      OnPropertyChanged();
    }
  }

  private object dataMapper;
  public object DataMapper
  {
    get => this.dataMapper;
    set
    {
      this.dataMapper = value;
      OnPropertyChanged();
    }
  }

  public ChartValues<ObservablePoint> ChartValues { get; set; }
  public Func<double, string> LabelFormatter => value => value.ToString("F");

  public event PropertyChangedEventHandler PropertyChanged;
  protected virtual void OnPropertyChanged([CallerMemberName] string propertyName = null) => this.PropertyChanged?.Invoke(this, new PropertyChangedEventArgs(propertyName));
}

<Window>
  <Window.DataContext>
    <DataModel />
  </Window.DataContext>

  <CartesianChart Height="500"
                  Zoom="None"
                  Hoverable="False"
                  DataTooltip="{x:Null}"
                  DisableAnimations="True">
    <wpf:CartesianChart.Series>
      <wpf:LineSeries PointGeometry="{x:Null}"
                      Title="Sine Graph"
                      Values="{Binding ChartValues}"
                      Configuration="{Binding DataMapper}"/>
    </wpf:CartesianChart.Series>

    <CartesianChart.CacheMode>
      <BitmapCache EnableClearType="False"
                   RenderAtScale="1"
                   SnapsToDevicePixels="False" />
    </CartesianChart.CacheMode>

    <CartesianChart.AxisY>
      <Axis Title="Sin(X)"
            FontSize="14"
            Unit="1"
            MaxValue="1.1"
            MinValue="-1.1"
            DisableAnimations="True"
            LabelFormatter="{Binding LabelFormatter}"
            Foreground="PaleVioletRed" />
    </CartesianChart.AxisY>

    <CartesianChart.AxisX>
      <Axis Title="X"
            DisableAnimations="True"
            FontSize="14"
            Unit="1"
            MaxValue="{Binding XMax}"
            MinValue="{Binding XMin}"
            Foreground="PaleVioletRed" />
    </CartesianChart.AxisX>
  </CartesianChart>
</Window>
