问在ReleaseFrame API中对DesktopDuplication ()的无效调用

EN

Windows 10.0.18362.0, 64 bits
Nvidia GeForce GTX 960, driver version 441.66

▬ Message -
HRESULT: [0x887A0001], Module: [SharpDX.DXGI], ApiCode: [DXGI_ERROR_INVALID_CALL/InvalidCall],
Message: The application made a call that is invalid. Either the parameters of the call or the state of some object was incorrect.
Enable the D3D debug layer in order to see details via debug messages.

○ Type -
    SharpDX.SharpDXException
▲ Source -
    SharpDX
▼ TargetSite -
    Void CheckError()
♠ StackTrace -
   at SharpDX.Result.CheckError()
   at SharpDX.DXGI.OutputDuplication.ReleaseFrame()
   at MyApp.Capture.DirectImageCapture.CaptureWithCursor(FrameInfo frame)

----------------------------------

▬ Message -
    Object reference not set to an instance of an object.
○ Type -
    System.NullReferenceException
▲ Source -
    SharpDX.Direct3D11
▼ TargetSite -
    Void GetDescription(SharpDX.Direct3D11.Texture2DDescription ByRef)
♠ StackTrace -
   at SharpDX.Direct3D11.Texture2D.GetDescription(Texture2DDescription& descRef)
   at MyApp.Capture.DirectImageCapture.GetCursor(Texture2D screenTexture, OutputDuplicateFrameInformation info, FrameInfo frame)
   at MyApp.Capture.DirectImageCapture.CaptureWithCursor(FrameInfo frame)

    var res = Result.Ok;

    try
    {
        //Try to get the duplicated output frame within given time.
        res = DuplicatedOutput.TryAcquireNextFrame(0, out var info, out var resource);

        //Checks how to proceed with the capture. It could have failed, or the screen, cursor or both could have been captured.
        if (res.Failure || resource == null || (info.AccumulatedFrames == 0 && info.LastMouseUpdateTime <= LastProcessTime))
        {
            //Somehow, it was not possible to retrieve the resource, frame or metadata.
            //frame.WasDropped = true;
            //BlockingCollection.Add(frame);

            resource?.Dispose();
            return FrameCount;
        }
        else if (info.AccumulatedFrames == 0 && info.LastMouseUpdateTime > LastProcessTime)
        {
            //Gets the cursor shape if the screen hasn't changed in between, so the cursor will be available for the next frame.
            GetCursor(null, info, frame);
            return FrameCount;
        }

        //Saves the most recent capture time.
        LastProcessTime = Math.Max(info.LastPresentTime, info.LastMouseUpdateTime);

        //Copy resource into memory that can be accessed by the CPU.
        using (var screenTexture = resource.QueryInterface<Texture2D>())
        {
            //Copies from the screen texture only the area which the user wants to capture.
            Device.ImmediateContext.CopySubresourceRegion(screenTexture, 0, new ResourceRegion(TrueLeft, TrueTop, 0, TrueRight, TrueBottom, 1), BackingTexture, 0);

            //Copy the captured desktop texture into a staging texture, in order to show the mouse cursor and not make the captured texture dirty with it.
            Device.ImmediateContext.CopyResource(BackingTexture, StagingTexture);

            //Gets the cursor image and merges with the staging texture.
            GetCursor(StagingTexture, info, frame);
        }

        //Get the desktop capture texture.
        var data = Device.ImmediateContext.MapSubresource(StagingTexture, 0, MapMode.Read, MapFlags.None);

        if (data.IsEmpty)
        {
            //frame.WasDropped = true;
            //BlockingCollection.Add(frame);

            Device.ImmediateContext.UnmapSubresource(StagingTexture, 0);
            resource.Dispose();
            return FrameCount;
        }

        #region Get image data

        var bitmap = new System.Drawing.Bitmap(Width, Height, PixelFormat.Format32bppArgb);
        var boundsRect = new System.Drawing.Rectangle(0, 0, Width, Height);

        //Copy pixels from screen capture Texture to the GDI bitmap.
        var mapDest = bitmap.LockBits(boundsRect, ImageLockMode.WriteOnly, bitmap.PixelFormat);
        var sourcePtr = data.DataPointer;
        var destPtr = mapDest.Scan0;

        for (var y = 0; y < Height; y++)
        {
            //Copy a single line.
            Utilities.CopyMemory(destPtr, sourcePtr, Width * 4);

            //Advance pointers.
            sourcePtr = IntPtr.Add(sourcePtr, data.RowPitch);
            destPtr = IntPtr.Add(destPtr, mapDest.Stride);
        }

        //Release source and dest locks.
        bitmap.UnlockBits(mapDest);

        //Set frame details.
        FrameCount++;
        frame.Path = $"{Project.FullPath}{FrameCount}.png";
        frame.Delay = FrameRate.GetMilliseconds(SnapDelay);
        frame.Image = bitmap;
        BlockingCollection.Add(frame);

        #endregion

        Device.ImmediateContext.UnmapSubresource(StagingTexture, 0);

        resource.Dispose();
        return FrameCount;
    }
    catch (SharpDXException se) when (se.ResultCode.Code == SharpDX.DXGI.ResultCode.WaitTimeout.Result.Code)
    {
        return FrameCount;
    }
    catch (SharpDXException se) when (se.ResultCode.Code == SharpDX.DXGI.ResultCode.DeviceRemoved.Result.Code || se.ResultCode.Code == SharpDX.DXGI.ResultCode.DeviceReset.Result.Code)
    {
        //When the device gets lost or reset, the resources should be instantiated again.
        DisposeInternal();
        Initialize();

        return FrameCount;
    }
    catch (Exception ex)
    {
        LogWriter.Log(ex, "It was not possible to finish capturing the frame with DirectX.");

        OnError.Invoke(ex);
        return FrameCount;
    }
    finally
    {
        try
        {
            //Only release the frame if there was a success in capturing it.
            if (res.Success)
                DuplicatedOutput.ReleaseFrame();
        }
        catch (Exception e)
        {
            LogWriter.Log(e, "It was not possible to release the frame.");

            //HERE
            //What should I do after the frame is not released properly?
            //Should I reset the whole capture?
            //DisposeInternal();
            //Initialize();
        }
    }

#if DEBUG
    Device = new Device(DriverType.Hardware, DeviceCreationFlags.VideoSupport | DeviceCreationFlags.Debug);

    var debug = InfoQueue.TryCreate();
    debug.SetBreakOnSeverity(DebugId.All, InformationQueueMessageSeverity.Corruption, true);
    debug.SetBreakOnSeverity(DebugId.All, InformationQueueMessageSeverity.Error, true);
    debug.SetBreakOnSeverity(DebugId.All, InformationQueueMessageSeverity.Warning, true);

    var debug2 = DXGIDebug.TryCreate();
    debug2.ReportLiveObjects(DebugId.Dx, DebugRloFlags.Summary | DebugRloFlags.Detail);

#else

00000001    0.00000000  [14488] OnFocusWindowChanged to Lizard Mode
00000002    0.39583239  [14488] Lizard Mode: Unprivileged process
00000003    0.39594769  [14488] Lizard Mode: Restoring app mapping
00000004    9.81729603  [21620] D3D11 WARNING: Process is terminating. Using simple reporting. Please call ReportLiveObjects() at runtime for standard reporting. [ STATE_CREATION WARNING #0: UNKNOWN]
00000005    9.81732273  [21620] D3D11: **BREAK** enabled for the previous message, which was: [ WARNING STATE_CREATION #0: UNKNOWN ]
00000006    9.81803799  [21620] DXGI WARNING: Process is terminating. Using simple reporting. Please call ReportLiveObjects() at runtime for standard reporting. [ STATE_CREATION WARNING #0: ]
00000007    9.81806469  [21620] DXGI: **BREAK** enabled for the previous message, which was: [ WARNING STATE_CREATION #0:  ]
00000008    10.78524113 [14488] Lizard Mode: Privileged process
00000009    10.78589630 [14488] Lizard Mode: Reverting to default M/KB Configuration
00000010    10.78692913 [14488] OnFocusWindowChanged to Lizard Mode
