社区首页 >问答首页 >WPF:使窗口不可调整,但保留框架吗?

WPF:使窗口不可调整,但保留框架吗?
EN

Stack Overflow用户
提问于 2010-08-02 09:26:30
回答 4查看 5.4K关注 0票数 8

我有一个没有标题栏(WindowStyle == WindowStyle.None)的窗口。整个窗口使用航空玻璃效果。当我使窗口不可调整大小(ResizeMode == ResizeMode.NoResize)时,玻璃效果就消失了,我的控制装置就挂在半空中。(从本质上说,窗口本身消失了,但却留下了内容。)

有什么办法可以让我的窗户在不摆脱窗框的情况下不能调整大小?

我读过https://stackoverflow.com/questions/1324398/enable-vista-glass-effect-on-a-borderless-wpf-window的问题,但这并不完全是我想要的--我想保留窗口的边框。关于我希望我的窗口是什么样子的一个例子,点击Alt+Tab并启用Aero。

为了澄清,不希望调整大小的游标在窗口边框上悬停时显示。这基本上就是我想让我的窗户看起来的样子:

解决方案不必严格使用WPF--为了实现这一点,我不介意使用Win32 API进行黑客操作。

EN

回答 4

Stack Overflow用户

回答已采纳

发布于 2010-08-11 20:54:05

您可以挂起wndproc并拦截温道普昌消息。不是严格意义上的WPF,但可能是你最好的选择。

如果您想隐藏调整大小的游标,那么最好的方法是拦截尼特泰斯特。调用DefWindowProc (获取默认行为)并测试返回值;如果是HTBOTTOM、HTBOTTOMLEFT、HTBOTTOMRIGHT、HTTOP、HTTOPLEFT或HTTOPRIGHT,则将返回值更改为HTBORDER。

票数 13
EN

Stack Overflow用户

发布于 2010-08-26 03:26:47

根据儿科学的答案。

代码语言:javascript
运行
复制
public partial class MainWindow : Window
{
    [DllImport("DwmApi.dll")]
    public static extern int DwmExtendFrameIntoClientArea(
        IntPtr hwnd,
        ref MARGINS pMarInset);

    [DllImport("user32.dll", CharSet = CharSet.Auto)]
    public static extern IntPtr DefWindowProc(
        IntPtr hWnd,
        int msg,
        IntPtr wParam,
        IntPtr lParam);

    private const int WM_NCHITTEST = 0x0084;
    private const int HTBORDER = 18;
    private const int HTBOTTOM = 15;
    private const int HTBOTTOMLEFT = 16;
    private const int HTBOTTOMRIGHT = 17;
    private const int HTLEFT = 10;
    private const int HTRIGHT = 11;
    private const int HTTOP = 12;
    private const int HTTOPLEFT = 13;
    private const int HTTOPRIGHT = 14;

    public MainWindow()
    {
        InitializeComponent();

        this.Loaded += new RoutedEventHandler(MainWindow_Loaded);
    }

    void MainWindow_Loaded(object sender, RoutedEventArgs e)
    {
        try
        {
            // Obtain the window handle for WPF application
            IntPtr mainWindowPtr = new WindowInteropHelper(this).Handle;
            HwndSource mainWindowSrc = HwndSource.FromHwnd(mainWindowPtr);
            mainWindowSrc.CompositionTarget.BackgroundColor = Color.FromArgb(0, 0, 0, 0);
            mainWindowSrc.AddHook(WndProc);

            // Set Margins
            MARGINS margins = new MARGINS();
            margins.cxLeftWidth = 10;
            margins.cxRightWidth = 10;
            margins.cyBottomHeight = 10;
            margins.cyTopHeight = 10;

            int hr = DwmExtendFrameIntoClientArea(mainWindowSrc.Handle, ref margins);
            //
            if (hr < 0)
            {
                //DwmExtendFrameIntoClientArea Failed
            }
        }
        // If not Vista, paint background white.
        catch (DllNotFoundException)
        {
            Application.Current.MainWindow.Background = Brushes.White;
        }
    }

    private IntPtr WndProc(IntPtr hwnd, int msg, IntPtr wParam, IntPtr lParam, ref bool handled)
    {
        // Override the window hit test
        // and if the cursor is over a resize border,
        // return a standard border result instead.
        if (msg == WM_NCHITTEST)
        {
            handled = true;
            var htLocation = DefWindowProc(hwnd, msg, wParam, lParam).ToInt32();
            switch (htLocation)
            {
                case HTBOTTOM:
                case HTBOTTOMLEFT:
                case HTBOTTOMRIGHT:
                case HTLEFT:
                case HTRIGHT:
                case HTTOP:
                case HTTOPLEFT:
                case HTTOPRIGHT:
                    htLocation = HTBORDER;
                    break;
            }

            return new IntPtr(htLocation);
        }

        return IntPtr.Zero;
    }

    private void Button_Click(object sender, RoutedEventArgs e)
    {
        this.Close();
    }
}

[StructLayout(LayoutKind.Sequential)]
public struct MARGINS
{
    public int cxLeftWidth;      // width of left border that retains its size
    public int cxRightWidth;     // width of right border that retains its size
    public int cyTopHeight;      // height of top border that retains its size
    public int cyBottomHeight;   // height of bottom border that retains its size
};

<Window x:Class="WpfApplication1.MainWindow"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    Title="MainWindow" Height="150" Width="200"
    Background="Transparent"
    WindowStyle="None"
    ResizeMode="CanResize"
>
    <Grid Background="White" Margin="10,10,10,10">
        <Button Content="Go Away" Click="Button_Click" Height="20" Width="100" />
    </Grid>
</Window>
票数 11
EN

Stack Overflow用户

发布于 2010-08-02 15:55:02

一种常见的方法是设置MinWidth/MaxWidth和MinHL.8/MaxHeight属性,从而有效地使其不可调整大小。当然,问题是您仍然会在边界上获得调整大小的游标。

票数 1
EN
