THREE.Box3Geometry = function (quadruplets, normals, debug) {

THREE.Geometry.call(this);

var constructee = this;  // constructee = the instance currently being constructed by the Box3Geometry constructor

buildPlane(quadruplets[0], normals[0], 0, debug); // px
buildPlane(quadruplets[1], normals[1], 1, debug); // nx
buildPlane(quadruplets[2], normals[2], 2); // py
buildPlane(quadruplets[3], normals[3], 3); // ny
buildPlane(quadruplets[4], normals[4], 4); // pz
buildPlane(quadruplets[5], normals[5], 5); // nz

function buildPlane(quadruplet, normal, materialIndex, debug) {

    if (debug) {
        console.log("materialIndex: ", materialIndex);
        console.log("normal: ", normal);
    }

    var offset = constructee.vertices.length;

    // populate the vertex array:
    constructee.vertices.push(quadruplet[0]);
    constructee.vertices.push(quadruplet[1]);
    constructee.vertices.push(quadruplet[2]);
    constructee.vertices.push(quadruplet[3]);

    // construct faceVertexUvs:
    var uva = new THREE.Vector2(0, 1);  //(u:0, v:1), uvb: (u:0, v:0) uvc: (u:1, v:0), uvd: (u:1, v:1)
    var uvb = new THREE.Vector2(0, 0);
    var uvc = new THREE.Vector2(1, 0);
    var uvd = new THREE.Vector2(1, 1);

    // construct faces:
    var a = 0;  // vertex: u:50, v:50
    var b = 2;  // vertex: u:50, v:-50
    var c = 3;  // vertex: u:-50, v:-50
    var d = 1;  // vertex: u:-50, v:50

    // decide the ordering of the face vertices:
    var reference_vertex = a + offset;
    var x = constructee.vertices[reference_vertex].clone().sub(normal);  // x: the normal relative to reference_vertex
    if (debug) { console.log("x: ", x); }
    var face_tangential_vector_b_a = constructee.vertices[b + offset].clone().sub(constructee.vertices[reference_vertex]);
    var face_tangential_vector_d_a = constructee.vertices[d + offset].clone().sub(constructee.vertices[reference_vertex]);
    var face_tangential_vector_x_a = x.sub(constructee.vertices[reference_vertex]);
    var matrix = utils.matrix_from_column_vectors(
        face_tangential_vector_b_a,
        face_tangential_vector_d_a,
        face_tangential_vector_x_a
    );
    var determinant = utils.matrix3Determinant(matrix);
    if (debug) { console.log("determinant: ", determinant); }

    // make two faces:
    if (determinant < 0) {
        var face1 = new THREE.Face3(a + offset, b + offset, d + offset);
        constructee.faceVertexUvs[ 0 ].push([ uva, uvb, uvd ]);
        var face2 = new THREE.Face3(b + offset, c + offset, d + offset);
        constructee.faceVertexUvs[ 0 ].push([ uvb.clone(), uvc, uvd.clone() ]);
    } else {
        var face1 = new THREE.Face3(a + offset, d + offset, b + offset);
        constructee.faceVertexUvs[ 0 ].push([ uva, uvd, uvb ]);
        var face2 = new THREE.Face3(b + offset, d + offset, c + offset);
        constructee.faceVertexUvs[ 0 ].push([ uvb.clone(), uvd.clone(), uvc ]);
    }

    face1.normal.copy(normal);
    face1.vertexNormals.push(normal.clone(), normal.clone(), normal.clone());
    face1.materialIndex = materialIndex;
    constructee.faces.push(face1);

    face2.normal.copy(normal);
    face2.vertexNormals.push(normal.clone(), normal.clone(), normal.clone());
    face2.materialIndex = materialIndex;
    constructee.faces.push(face2);

    if (false) {
        console.log("materialIndex: ", materialIndex);
        console.log("a: %d, vertex: x:%f, y:%f, z:%f", a, constructee.vertices[a][x], constructee.vertices[a][y], constructee.vertices[a][z]);
        console.log("b: %d, vertex: x:%f, y:%f, z:%f", b, constructee.vertices[b][x], constructee.vertices[b][y], constructee.vertices[b][z]);
        console.log("c: %d, vertex: x:%f, y:%f, z:%f", c, constructee.vertices[c][x], constructee.vertices[c][y], constructee.vertices[c][z]);
        console.log("d: %d, vertex: x:%f, y:%f, z:%f", d, constructee.vertices[d][x], constructee.vertices[d][y], constructee.vertices[d][z]);
        console.log("face1: a: (x:%f, y:%f, z:%f), b: (x:%f, y:%f, z:%f), d: (x:%f, y:%f, z:%f)",
    face1.a.getComponent[0], face1.a.getComponent[1], face1.a.getComponent[2],
    face1.b.getComponent[0], face1.b.getComponent[1], face1.b.getComponent[2],
    face1.c.getComponent[0], face1.c.getComponent[1], face1.c.getComponent[2]);
        console.log("face2: a: (u:%f, v:%f), c: (u:%f, v:%f), d: (u:%f, v:%f)",
    constructee.vertices[b + offset][u], constructee.vertices[b + offset][v],
    constructee.vertices[c + offset][u], constructee.vertices[c + offset][v],
    constructee.vertices[d + offset][u], constructee.vertices[d + offset][v]);
        console.log("uva: (u:%f, v:%f), uvb: (u:%f, v:%f) uvc: (u:%f, v:%f), uvd: (u:%f, v:%f)",
    uva.getComponent(0), uva.getComponent(1),
    uvb.getComponent(0), uvb.getComponent(1),
    uvc.getComponent(0), uvc.getComponent(1),
    uvd.getComponent(0), uvd.getComponent(1));
        console.log(" ");
    }


    if (false) {
        console.log("segUi: %d, segVi: %d, uDir: %d, vDir: %d", segUi, segVi, uDir, vDir);
        console.log("segmentDist_u: %f, segmentDist_v: %f", segmentDist_u, segmentDist_v);
        console.log(" vertex[ u ] = ( iu * segmentDist_u - uDist_half ) * uDir\n" +
    " vertex[ v ] = ( iv * segmentDist_v - vDist_half ) * vDir\n" +
    " vertex[ w ] = wDist_half");
        console.log(" "); }


};
this.mergeVertices();
};
THREE.Box3Geometry.prototype = Object.create(THREE.Geometry.prototype);

THREE.BoxHelper( mesh )
THREE.FaceNormalsHelper( mesh )
THREE.VertexNormalsHelper( mesh )
THREE.WireframeHelper( mesh )
