跨地域复制配置

最近更新时间:2019-07-02 17:22:54

适用场景

通过配置跨地域复制规则,可以将用户的对象数据从源存储桶中复制到另一区域的指定目标存储桶中。跨地域复制的适用场景包括异地容灾、满足行业合规性要求、数据迁移和备份、减少客户访问延迟、方便不同区域的集群访问数据等原因。

使用方法

使用对象存储控制台

通过对象存储控制台设置跨地域复制规则,请参见 设置跨地域复制 控制台指南文档。

使用 REST API

您可以直接使用 REST API 配置和管理存储桶的跨地域复制规则,具体可参考以下 API 文档:

使用 C++ SDK

对象存储 COS 的 C++ SDK 中提供了该方法,请参见 C++ 存储桶管理 文档进行设置。

步骤说明:

  1. 初始化客户端 cosClient。
  2. 执行 PutBucketReplication、GetBucketReplication 和 DeleteBucketReplication 分别实现配置跨地域复制规则、获取跨地域复制规则和删除跨地域复制规则三种操作。

配置跨地域复制规则

代码示例:

qcloud_cos::CosConfig config("./config.json");
qcloud_cos::CosAPI cos(config);

std::string bucket_name = "cpp_sdk_v5-123456789";

// PutBucketReplicationReq 的构造函数需要传入 bucket_name
qcloud_cos::PutBucketReplicationReq req(bucket_name);
req.SetRole("qcs::cam::uin/***:uin/****");
qcloud_cos::ReplicationRule rule("sevenyou_10m", "qcs:id/0:cos:cn-south:appid/***:sevenyousouthtest", "", "RuleId_01", true);
req.AddReplicationRule(rule)

qcloud_cos::PutBucketReplicationResp resp;
qcloud_cos::CosResult result = cos.PutBucketReplication(req, &resp);

// 调用成功,调用 resp 的成员函数获取返回内容
if (result.IsSucc()) {
    // ...
} else {
    // 设置跨地域复制失败,可以调用 CosResult 的成员函数输出错误信息,如 requestID 等
}

获取跨地域复制规则

代码示例:

qcloud_cos::CosConfig config("./config.json");
qcloud_cos::CosAPI cos(config);

std::string bucket_name = "cpp_sdk_v5-123456789";

// GetBucketReplicationReq 的构造函数需要传入 bucket_name
qcloud_cos::GetBucketReplicationReq req(bucket_name);
qcloud_cos::GetBucketReplicationResp resp;
qcloud_cos::CosResult result = cos.GetBucketReplication(req, &resp);

// 调用成功,调用 resp 的成员函数获取返回内容
if (result.IsSucc()) {
    // ...
} else {
    // 获取跨地域复制配置失败,可以调用 CosResult 的成员函数输出错误信息,如 requestI 等
}

删除跨地域复制规则

代码示例:

qcloud_cos::CosConfig config("./config.json");
qcloud_cos::CosAPI cos(config);

std::string bucket_name = "cpp_sdk_v5-123456789";

// DeleteBucketReplicationReq 的构造函数需要传入 bucket_name
qcloud_cos::DeleteBucketReplicationReq req(bucket_name);
qcloud_cos::DeleteBucketReplicationResp resp;
qcloud_cos::CosResult result = cos.DeleteBucketReplication(req, &resp);

// 调用成功,调用 resp 的成员函数获取返回内容
if (result.IsSucc()) {
    // ...
} else {
    // 删除跨地域复制配置失败,可以调用 CosResult 的成员函数输出错误信息,如 requestID 等
}

使用 C SDK

对象存储 COS 的 C SDK 中提供了该方法,请参见 C SDK 存储桶管理 进行设置。

步骤说明:

  1. 初始化客户端 cosClient
  2. 执行 PutBucketReplication、GetBucketReplication 和 DeleteBucketReplication 分别实现配置跨地域复制规则、获取跨地域复制规则和删除跨地域复制规则三种操作。

配置跨地域复制规则

代码示例:

cos_pool_t *p = NULL;
int is_cname = 0;
cos_status_t *s = NULL;
cos_request_options_t *options = NULL;
cos_string_t bucket;
cos_table_t *resp_headers = NULL;

//create memory pool
cos_pool_create(&p, NULL);

//init request options
options = cos_request_options_create(p);
options->config = cos_config_create(options->pool);
init_test_config(options->config, is_cname);
cos_str_set(&options->config->endpoint, TEST_COS_ENDPOINT);
cos_str_set(&options->config->access_key_id, TEST_ACCESS_KEY_ID);
cos_str_set(&options->config->access_key_secret, TEST_ACCESS_KEY_SECRET);
cos_str_set(&options->config->appid, TEST_APPID);
options->config->is_cname = is_cname;
options->ctl = cos_http_controller_create(options->pool, 0);
cos_str_set(&bucket, TEST_BUCKET_NAME);

//put bucket replication
cos_replication_params_t *replication_param = NULL;
replication_param = cos_create_replication_params(p);
cos_str_set(&replication_param->role, "qcs::cam::uin/100000616666:uin/100000616666");

cos_replication_rule_content_t *rule = NULL;
rule = cos_create_replication_rule_content(p);
cos_str_set(&rule->id, "Rule_01");
cos_str_set(&rule->status, "Enabled");
cos_str_set(&rule->prefix, "test1");
cos_str_set(&rule->dst_bucket, "qcs:id/0:cos:cn-east:appid/1253686666:replicationtest");
cos_list_add_tail(&rule->node, &replication_param->rule_list);

rule = cos_create_replication_rule_content(p);
cos_str_set(&rule->id, "Rule_02");
cos_str_set(&rule->status, "Disabled");
cos_str_set(&rule->prefix, "test2");
cos_str_set(&rule->storage_class, "Standard_IA");
cos_str_set(&rule->dst_bucket, "qcs:id/0:cos:cn-east:appid/1253686666:replicationtest");
cos_list_add_tail(&rule->node, &replication_param->rule_list);

rule = cos_create_replication_rule_content(p);
cos_str_set(&rule->id, "Rule_03");
cos_str_set(&rule->status, "Enabled");
cos_str_set(&rule->prefix, "test3");
cos_str_set(&rule->storage_class, "Standard_IA");
cos_str_set(&rule->dst_bucket, "qcs:id/0:cos:cn-east:appid/1253686666:replicationtest");
cos_list_add_tail(&rule->node, &replication_param->rule_list);

s = cos_put_bucket_replication(options, &bucket, replication_param, &resp_headers);
if (cos_status_is_ok(s)) {
printf("put bucket replication succeeded\n");
} else {
printf("put bucket replication failed\n");
}

//destroy memory pool
cos_pool_destroy(p);

获取跨地域复制规则

代码示例:

cos_pool_t *p = NULL;
int is_cname = 0;
cos_status_t *s = NULL;
cos_request_options_t *options = NULL;
cos_string_t bucket;
cos_table_t *resp_headers = NULL;

//create memory pool
cos_pool_create(&p, NULL);

//init request options
options = cos_request_options_create(p);
options->config = cos_config_create(options->pool);
init_test_config(options->config, is_cname);
cos_str_set(&options->config->endpoint, TEST_COS_ENDPOINT);
cos_str_set(&options->config->access_key_id, TEST_ACCESS_KEY_ID);
cos_str_set(&options->config->access_key_secret, TEST_ACCESS_KEY_SECRET);
cos_str_set(&options->config->appid, TEST_APPID);
options->config->is_cname = is_cname;
options->ctl = cos_http_controller_create(options->pool, 0);
cos_str_set(&bucket, TEST_BUCKET_NAME);

//get bucket replication
cos_replication_params_t *replication_param2 = NULL;
replication_param2 = cos_create_replication_params(p);
s = cos_get_bucket_replication(options, &bucket, replication_param2, &resp_headers);

if (cos_status_is_ok(s)) {
printf("get bucket replication succeeded\n");
printf("ReplicationConfiguration role: %s\n", replication_param2->role.data);
cos_replication_rule_content_t *content = NULL;
cos_list_for_each_entry(cos_replication_rule_content_t, content, &replication_param2->rule_list, node) {
printf("ReplicationConfiguration rule, id:%s, status:%s, prefix:%s, dst_bucket:%s, storage_class:%s\n",
content->id.data, content->status.data, content->prefix.data, content->dst_bucket.data, content->storage_class.data);
}
} else {
printf("get bucket replication failed\n");
}

//destroy memory pool
cos_pool_destroy(p);

删除跨地域复制规则

cos_pool_t *p = NULL;
int is_cname = 0;
cos_status_t *s = NULL;
cos_request_options_t *options = NULL;
cos_string_t bucket;
cos_table_t *resp_headers = NULL;

//create memory pool
cos_pool_create(&p, NULL);

//init request options
options = cos_request_options_create(p);
options->config = cos_config_create(options->pool);
init_test_config(options->config, is_cname);
cos_str_set(&options->config->endpoint, TEST_COS_ENDPOINT);
cos_str_set(&options->config->access_key_id, TEST_ACCESS_KEY_ID);
cos_str_set(&options->config->access_key_secret, TEST_ACCESS_KEY_SECRET);
cos_str_set(&options->config->appid, TEST_APPID);
options->config->is_cname = is_cname;
options->ctl = cos_http_controller_create(options->pool, 0);
cos_str_set(&bucket, TEST_BUCKET_NAME);

//delete bucket cors
s = cos_delete_bucket_replication(options, &bucket, &resp_headers);
if (cos_status_is_ok(s)) {
printf("delete bucket replication succeeded\n");
} else {
printf("delete bucket replication failed\n");
}

//destroy memory pool
cos_pool_destroy(p);
