【CC2530开发基础篇】DHT11温湿度传感器

/****************************************************************************
* 文 件 名: main.c
* 描    述: 将采集到的温湿度通过串口发送到串口调试助手上显示 9600 8N1
****************************************************************************/
#include <ioCC2530.h>
#include <string.h>
#include "UART.H"
#include "DHT11.H"

/****************************************************************************
* 程序入口函数
****************************************************************************/
void main(void)
{
    uchar temp[3];
    uchar humidity[3];
    uchar strTemp[13]="Temperature:";
    uchar strHumidity[10]="Humidity:";

    Delay_ms(1000);          //让设备稳定
    InitUart();              //串口初始化
    while(1)
    {
        memset(temp, 0, 3);
        memset(humidity, 0, 3);

        DHT11();             //获取温湿度

        //将温湿度的转换成字符串
        temp[0]=wendu_shi+0x30;
        temp[1]=wendu_ge+0x30;
        humidity[0]=shidu_shi+0x30;
        humidity[1]=shidu_ge+0x30;

        //获得的温湿度通过串口输出到电脑显示
        UartSendString(strTemp, 12);
        UartSendString(temp, 2);
        UartSendString("   ", 3);
        UartSendString(strHumidity, 9);
        UartSendString(humidity, 2);
        UartSendString("\n", 1);

        Delay_ms(3000);  //延时，2S读取1次
    }
}

#include <ioCC2530.h>

typedef unsigned char uchar;
typedef unsigned int  uint;

#define DATA_PIN P0_7

//温湿度定义
uchar ucharFLAG,uchartemp;
uchar shidu_shi,shidu_ge,wendu_shi,wendu_ge=4;
uchar ucharT_data_H,ucharT_data_L,ucharRH_data_H,ucharRH_data_L,ucharcheckdata;
uchar ucharT_data_H_temp,ucharT_data_L_temp,ucharRH_data_H_temp,ucharRH_data_L_temp,ucharcheckdata_temp;
uchar ucharcomdata;

//延时函数
void Delay_us() //1 us延时
{
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
    asm("nop");
}

void Delay_10us() //10 us延时
{
  #if 0
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  Delay_us();
  #else
    int i = 10;
    while(i--);
#endif
}

void Delay_ms(uint Time)//n ms延时
{
    unsigned char i;
    while(Time--)
    {
        for(i=0;i<100;i++)
            Delay_10us();
    }
}

//温湿度传感
void COM(void)    // 温湿写入
{
    uchar i;
    for(i=0;i<8;i++)
    {
        ucharFLAG=2;
        while((!DATA_PIN)&&ucharFLAG++);
        Delay_10us();
        Delay_10us();
        Delay_10us();
        uchartemp=0;
        if(DATA_PIN)uchartemp=1;
        ucharFLAG=2;
        while((DATA_PIN)&&ucharFLAG++);
        if(ucharFLAG==1)break;
        ucharcomdata<<=1;
        ucharcomdata|=uchartemp;
    }
}

void DHT11(void)   //温湿传感启动
{
    DATA_PIN=0;
    Delay_ms(19);  //>18MS
    DATA_PIN=1;
    P0DIR &= ~0x80; //重新配置IO口方向
    Delay_10us();
    Delay_10us();
    Delay_10us();
    Delay_10us();
    if(!DATA_PIN)
    {
        ucharFLAG=2;
        while((!DATA_PIN)&&ucharFLAG++);
        ucharFLAG=2;
        while((DATA_PIN)&&ucharFLAG++);
        COM();
        ucharRH_data_H_temp=ucharcomdata;
        COM();
        ucharRH_data_L_temp=ucharcomdata;
        COM();
        ucharT_data_H_temp=ucharcomdata;
        COM();
        ucharT_data_L_temp=ucharcomdata;
        COM();
        ucharcheckdata_temp=ucharcomdata;
        DATA_PIN=1;
        uchartemp=(ucharT_data_H_temp+ucharT_data_L_temp+ucharRH_data_H_temp+ucharRH_data_L_temp);
        if(uchartemp==ucharcheckdata_temp)
        {
            ucharRH_data_H=ucharRH_data_H_temp;
            ucharRH_data_L=ucharRH_data_L_temp;
            ucharT_data_H=ucharT_data_H_temp;
            ucharT_data_L=ucharT_data_L_temp;
            ucharcheckdata=ucharcheckdata_temp;
        }
        wendu_shi=ucharT_data_H/10;
        wendu_ge=ucharT_data_H%10;

        shidu_shi=ucharRH_data_H/10;
        shidu_ge=ucharRH_data_H%10;
    }
    else //没用成功读取，返回0
    {
        wendu_shi=0;
        wendu_ge=0;

        shidu_shi=0;
        shidu_ge=0;
    }

    P0DIR |= 0x80; //IO口需要重新配置
}

#ifndef __UART_H__
#define __UART_H__

extern void InitUart();   //初始化串口
extern void UartSendString(unsigned char *Data,int len);

#endif
