腾讯云容器服务 TKE 现已支持多个 Ingress 复用同一负载均衡器。如需将多个 Ingress 的流量聚合到单一负载均衡器入口,您可以在创建 Ingress 资源时为其添加
ingress.cloud.tencent.com/enable-group: 'true' 注解,并使用 kubernetes.io/ingress.existLbId: lb-xxxxxxxx 注解指向相同的 CLB 实例。注意事项
多个 Ingress 复用同一个 CLB 时,不支持与 Service 共用该 CLB。
此功能必须在创建 Ingress 时启用。对于已创建的 Ingress,暂时不支持追加开启。
不支持复用由 TKE CLB Ingress 自动创建的 CLB。
请注意,多个 Ingress 复用同一个 CLB 可能会创建更多的监听器或转发规则,而 CLB 存在账号和实例维度的配额限制,为避免触达上限影响 Ingress 同步,请联系负载均衡团队 提交工单 以规划合理的配额。
警告:
多个 Ingress 复用 CLB 时,若发生配置冲突,Ingress Controller 将中断调谐并报错,为了避免影响 Ingress 同步规则和配置,请关注 Ingress 并及时处理错误!
使用前提
确保集群内 Service/Ingress Controller 版本 ≥ v2.10.0 且运行在融合版本(Ingress Controller 已融合至 Service Controller 组件)模式。如未满足,请 提交工单 联系 TKE 团队升级。
说明:
Service/Ingress Controller 版本:您可以在 TKE 集群的
kube-system 命名空间下,查看 configmap tke-service-controller-config 和 tke-ingress-controller-config 中的 VERSION 参数,以获取对应组件的版本信息。融合版本说明:当 tke-service-controller-config 中的
EnableIngressController 参数值为 'true' 时,表示已启用融合版本模式。使用方式
多个 Ingress 可以复用相同的监听器(端口)或域名,但必须确保每个“域名 + URL 路径”的规则组合是唯一的。
支持跨命名空间(Namespace)的多个 Ingress 复用同一个 CLB。
部分功能特性在复用场景下不受支持,相关错误将在 Ingress 事件/注解 中提示。
注意:
注解
ingress.cloud.tencent.com/enable-group: 'true' 需要在创建 Ingress 时与 kubernetes.io/ingress.existLbId: lb-xxxxxxxx 同时指定,对已有 Ingress 添加注解无法启用该功能。前置条件

使用示例
apiVersion: v1kind: Namespacemetadata:name: ns1---apiVersion: v1kind: Namespacemetadata:name: ns2---apiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 80}]'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 请修改成自己的clb idingress.cloud.tencent.com/enable-group: 'true' # 必须在 ingress 创建时指定name: nginx-ingress-1namespace: ns1spec:rules:- http:paths:- backend:service:name: nginx-serviceport:number: 80path: /pathType: ImplementationSpecific---apiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 81}]'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 请修改成自己的clb idingress.cloud.tencent.com/enable-group: 'true'name: nginx-ingress-2namespace: ns2spec:rules:- http:paths:- backend:service:name: nginx-serviceport:number: 80path: /pathType: ImplementationSpecific
apiVersion: v1kind: Namespacemetadata:name: ns1---apiVersion: v1kind: Namespacemetadata:name: ns2---apiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 80}]'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 请修改成自己的clb idingress.cloud.tencent.com/enable-group: 'true' # 必须在新建ingress时和 kubernetes.io/ingress.existLbId 同时指定kubernetes.io/ingress.http-rules: '[{"host":"example.com","path":"/api","backend":{"serviceName":"anyserver","servicePort":"80"}},{"host":"example.com","path":"/tmp","rewrite":{"port":80,"host":"example.com","path":"/api"}}]'kubernetes.io/ingress.https-rules: "null"kubernetes.io/ingress.rule-mix: "true"name: nginx-ingress-1namespace: ns1spec:rules:- http:paths:- backend:service:name: nginx-serviceport:number: 80path: /pathType: ImplementationSpecific---apiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 80}]'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 请修改成自己的clb idingress.cloud.tencent.com/enable-group: 'true'name: nginx-ingress-2namespace: ns2spec:rules:- http:paths:- backend:service:name: nginx-serviceport:number: 80path: /homepathType: ImplementationSpecific
# 示例:不同 Ingress 复用相同 CLB 监听器,各自使用不同域名# 说明:# - 两个 Ingress 位于不同命名空间(ns1 和 ns2)# - 复用相同的 CLB(通过 kubernetes.io/ingress.existLbId 指定)# - 复用相同的监听器端口(80 和 8080)# - 各自使用不同的域名进行路由# - ns1 的 Ingress 使用域名: app1.example.com# - ns2 的 Ingress 使用域名: app2.example.comapiVersion: v1kind: Namespacemetadata:name: ns1---apiVersion: v1kind: Namespacemetadata:name: ns2---# Ingress 1: 使用域名 app1.example.comapiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 80}]'ingress.cloud.tencent.com/enable-group: 'true'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 这里需要填写你自己的lbidname: app1-ingressnamespace: ns1spec:rules:- host: app1.example.comhttp:paths:- backend:service:name: app1-serverport:number: 80path: /pathType: Prefix---# Ingress 2: 使用域名 app2.example.com(复用相同的 CLB 和监听器)apiVersion: networking.k8s.io/v1kind: Ingressmetadata:annotations:ingress.cloud.tencent.com/listen-ports: '[{"HTTP": 80}]'ingress.cloud.tencent.com/enable-group: 'true'kubernetes.io/ingress.existLbId: lb-xxxxxxxx # 这里需要填写你自己的lbid(与上面相同)name: app2-ingressnamespace: ns2spec:rules:- host: app2.example.comhttp:paths:- backend:service:name: app2-serverport:number: 80path: /pathType: Prefix---# ns1 的 ServiceapiVersion: v1kind: Servicemetadata:name: app1-servernamespace: ns1labels:app: app1-serverspec:ports:- name: httpport: 80targetPort: 80selector:app: app1-servertype: NodePort---# ns1 的 DeploymentapiVersion: apps/v1kind: Deploymentmetadata:name: app1-servernamespace: ns1spec:replicas: 1selector:matchLabels:app: app1-servertemplate:metadata:labels:app: app1-serverspec:containers:- image: ccr.ccs.tencentyun.com/paas/anyservername: anyserverenv:- name: POD_NAMEvalueFrom:fieldRef:apiVersion: v1fieldPath: metadata.name---# ns2 的 ServiceapiVersion: v1kind: Servicemetadata:name: app2-servernamespace: ns2labels:app: app2-serverspec:ports:- name: httpport: 80targetPort: 80selector:app: app2-servertype: NodePort---# ns2 的 DeploymentapiVersion: apps/v1kind: Deploymentmetadata:name: app2-servernamespace: ns2spec:replicas: 1selector:matchLabels:app: app2-servertemplate:metadata:labels:app: app2-serverspec:containers:- image: ccr.ccs.tencentyun.com/paas/anyservername: anyserverenv:- name: POD_NAMEvalueFrom:fieldRef:apiVersion: v1fieldPath: metadata.name
支持进度
注解 | 解释 | 是否支持(复用场景下) |
ingress.cloud.tencent.com/listen-ports | 自定义监听端口 | 支持 |
ingress.cloud.tencent.com/direct-access | 开启 CLB 直通 Pod | 支持 |
ingress.cloud.tencent.com/auto-rewrite | 使用自动重定向 | 支持 |
kubernetes.io/ingress.rule-mix | 开启混合(http/https)协议 | 支持 |
kubernetes.io/ingress.http-rules | http 协议 | 支持 |
kubernetes.io/ingress.https-rules | https 协议 | 支持 |
ingress.cloud.tencent.com/enable-grace-deletion | Pod 优雅删除 | 支持 |
ingress.cloud.tencent.com/lb-rs-weight | 自定义后端 RS 权重 | 支持 |
ingress.cloud.tencent.com/tke-service-config | 使用手动拓展配置 | 支持 |
ingress.cloud.tencent.com/pass-to-target | 默认放通 | 支持 |
ingress.cloud.tencent.com/tke-service-config-auto | 使用自动生成拓展配置 | 不支持 |
ingress.cloud.tencent.com/rewrite-support | 使用手动重定向 | 废弃 |
功能变更说明
部分注解在多个 Ingress 复用 CLB 场景下的使用方式和语义有所调整。
手动重定向
注解:
ingress.cloud.tencent.com/rewrite-support状态:在多个 Ingress 复用 CLB 场景下废弃。
说明:该注解已废弃,为 Ingress 变更手动重定向规则只需在
kubernetes.io/ingress.http-rules 和 kubernetes.io/ingress.https-rules 中配置,无需添加此注解。自动重定向
注解:
ingress.cloud.tencent.com/auto-rewrite改动:在多个 Ingress 复用 CLB 场景下调整注解删除的语义。
说明:在多个 Ingress 复用 CLB 的场景下,删除该注解与将其值设为
false 均表示关闭自动重定向。常见问题
存量使用已有 CLB 的 Ingress 迁移问题
暂不支持通过为存量的 Ingress 添加注解
ingress.cloud.tencent.com/enable-group: 'true' 以迁移到复用场景。规则/配置冲突问题
控制器正常调谐时,Ingress 注解示例如下:
ingress.cloud.tencent.com/status.conditions: '[{"type":"Ready","status":"True","lastTransitionTime":"2025-10-07T11:30:53Z","reason":"Success","message":""}]'
若复用同一 CLB 的 Ingress 出现调谐异常,错误信息将暴露于注解中,例如:
ingress.cloud.tencent.com/status.conditions: '[{"type":"Ready","status":"False","lastTransitionTime":"2025-10-07T11:35:10Z","reason":"ListenerError","message":"SyncClientError\\nErrorCode: E4403\\nDetails: Group: lb-fgim8ppi. The loadbalancerhas port conflict in the listeners 80_HTTP.\\nOriginError: ingress ns1/server2listener 80_HTTP domain example.com's path / conflict: already owned by ns1/server1\\n"}]'
场景支持问题
复用 CLB 的 Ingress 不支持与使用已有 CLB 的 Ingress(未指定
ingress.cloud.tencent.com/enable-group: 'true'注解) 共用同一 CLB,报错示例如下:ingress.cloud.tencent.com/status.conditions: '[{"type":"Ready","status":"False","lastTransitionTime":"2025-10-09T12:29:05Z","reason":"LoadbalancerError","message":"SyncClientError\\nErrorCode: E4406\\nDetails: Group: lb-fgim8ppi. Can not use lb:ns1/server1 used by another ingress/multiClusterIngress .\\nOriginError:group can't reuse clb with ingress which has existLbId, please process\\n"}]'
复用 CLB 的 Ingress 暂不支持与 Service 共用同一 CLB,报错示例如下:
ingress.cloud.tencent.com/status.conditions: '[{"type":"Ready","status":"False","lastTransitionTime":"2025-10-09T12:40:01Z","reason":"LoadbalancerError","message":"SyncClientError\\nErrorCode: E4407\\nDetails: Group: lb-fgim8ppi. Can not use lb:lb-fgim8ppi used by another service ns1/svc1.\\nOriginError: ingress managered by group not support reuse clb with service\\n"}]'
