腾讯云 Elasticsearch Service COS快照恢复常见问题及解决方案

原创
作者头像
zjiekou
发布于 2023-12-06 15:51:14
发布于 2023-12-06 15:51:14
1.1K00
代码可运行
举报
文章被收录于专栏:大数据zjiekou大数据zjiekou
运行总次数:0
代码可运行

一、前言

用户在腾讯云上自建的 ES 集群或者在其它云厂商购买的 ES 集群,如果要迁移至腾讯云 ES(适用于大部分普通索引迁移),用户可以根据自己的业务需要选择合适的迁移方案。如果业务可以停服或者可以暂停写操作,可以使用以下几种方式进行数据迁移

  1. COS 快照
  2. logstash
  3. elasticsearch-dump 具体实践可参考官网文档:https://cloud.tencent.com/document/product/845/35568

二、常见报错场景

1、创建repository 仓库报错my_cos_backup path is not accessible on master node

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
{
  "error" : {
    "root_cause" : [
      {
        "type" : "repository_verification_exception",
        "reason" : "[my_cos_backup] path  is not accessible on master node"
      }
    ],
    "type" : "repository_verification_exception",
    "reason" : "[my_cos_backup] path  is not accessible on master node",
    "caused_by" : {
      "type" : "i_o_exception",
      "reason" : "Exception when write blob master.dat",
      "caused_by" : {
        "type" : "cos_service_exception",
        "reason" : "cos_service_exception: The specified bucket does not exist. (Status Code: 404; Error Code: NoSuchBucket; Request ID: NjUzYzkwYmRfMzAxNzUyMWVfMjJmYmNfYTJkOGY1Ng==); Trace ID: OGVmYzZiMmQzYjA2OWNhODk0NTRkMTBiOWVmMDAxODc1NGE1MWY0MzY2NTg1MzM1OTY3MDliYzY2YTQ0ZThhMDFhOWZlZTQxMzRkMTQ2NGM4MmFlZDk1MTQzM2UyMTll"
      }
    }
  },
  "status" : 500
}

报错原因:bucket和app_id参数入参有误,bucket经常会有客户把桶appid完整复制上导致出错、app_id填成UIN也会有这个问题。

解决方案:

bucket:COS Bucket 名字,不带 appId 后缀的 bucket 名

app_id:腾讯云账号 APPID

二、cos快照恢复集群red,"explanation": "node does not match index setting index.routing.allocation.require filters temperature:\"hot\""

报错原因:通常是由于客户将热节点的集群通过cos快照迁移到温节点的集群会出现这个问题,这个意思是说用户在目标集群恢复的时候 因为磁盘属性不同,导致数据恢复失败。 做快照的集群是ssd的,SSD磁盘的数据节点默认是hot属性的, 需要恢复的集群时高性能云硬盘,高性能云盘的数据节点默认是warm属性的 。从hot节点集群恢复到warm节点集群就会出现这个冲突异常。

解决方案:

先删除之前恢复的索引,然后在恢复的命令中,加以下相关参数

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
POST _snapshot/cos_backup/snapshot_名称/_restore
{
  "indices": "*,-.monitoring*,-.security*,-.kibana*",
  "ignore_unavailable": true,
  "ignore_index_settings": [
    "index.routing.allocation.require.temperature"
  ]
}

三、ES 8.8.1版本创建仓库报错{"error":{"root_cause":[{"type":"repository_exception","reason":"my_cos_repository No region defined for cos repository"}],"type":"repository_exception","reason":"my_cos_repository failed to create repository","caused_by":{"type":"repository_exception","reason":"my_cos_repository No region defined for cos repository"}},"status":500}

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
curl -u 'elastic:xxxx' -X PUT 'http://xxxxx:9200/_snapshot/my_cos_repository' -H "Content-Type: application/json" -d '
{
  "type": "cos",
  "settings": {
    "bucket": "xxx",
    "region": "ap-shanghai",
    "access_key_id": "XXX",
    "access_key_secret": "XXX",
    "base_path": "/",
    "app_id": "xxxx"
  }
}
'

解决方案:

8.8.1版本需要这样创建

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
PUT _snapshot/my_cos_backup
{
  "type": "cos",
  "settings": {
    "compress": true,
    "chunk_size": "500mb",
    "cos": {
      "client": {
        "app_id": "xxxx",
        "access_key_id": "xxxx",
        "access_key_secret": "xxxx",
        "bucket": "xxxx",
        "region": "ap-guangzhou",
        "base_path": "/"
      }
    }
  }
}

四、快照恢复报错

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
{
  "statusCode": 400,
  "error": "Bad Request",
  "message": "Alias [.kibana] has more than one indices associated with it [[.kibana_2_backup, .kibana_1]], can't execute a single index op: [illegal_argument_exception] Alias [.kibana] has more than one indices associated with it [[.kibana_2_backup, .kibana_1]], can't execute a single index op"
}

解决方案:

恢复ES备份的时候,把源集群的.kibana_1和.kibana_2也复制过来了,这个.kibana_2的别名是.kibana。导致冲突了。

首先移除.kibana_2别名

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
POST _aliases
{
  "actions": [
    {
      "remove": {
        "index": ".kibana_2",
        "alias": ".kibana"
      }
    }
  ]
}

关闭索引自动创建

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
PUT _cluster/settings
{
  "persistent": {
    "action.auto_create_index": false
  }
}

操作完成后重新进行恢复数据操作

多可用区集群增量恢复报错

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
{"unassigned_info":{"reason":"EXISTING_INDEX_RESTORED","details":"restore_source[my_cos_backup/snapshot_2]"},"node_allocation_decisions":[{"deciders":[{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]},{"deciders":[{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]},{"deciders":[{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]},{"deciders":[{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]},{"deciders":[{"explanation":"the shard cannot be allocated to the same node on which a copy of the shard already exists [[sel_pitem_his][2], node[Tg4tV6mcT22SO_0ZCfWHWA], [R], s[STARTED], a[id=X7H-v4fRQTaWnOPsu3j7KA]]"},{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]},{"deciders":[{"explanation":"the shard cannot be allocated to the same node on which a copy of the shard already exists [[sel_pitem_his][2], node[b2RSlGbNR82IU_1j1HShJw], [P], s[STARTED], a[id=UXIVucaDQkyNSQ5syzrkwA]]"},{"explanation":"there are too many copies of the shard allocated to nodes with attribute [set], there are [3] total configured shard copies for this shard id and [3] total attribute values, expected the allocated shard count per attribute [2] to be less than or equal to the upper bound of the required number of shards per attribute [1]"}]}]}

解决方案:

方案一

结合集群环境,计算副本数目

不需要调整的副本数目需要用以下公式计算:

ceil{(replicas + 1) / (可用区+1)} = ceil{(replicas + 1) / 可用区}

repilcas <= 总节点数 -1

以2可用区,单可用区3节点为例

replicas可用值为:0,1,3

然后获取集群所有索引分片数目,如果和上述结果不一致,则挂起

方案二

换一个思路,分片迁移出现异常是由于awareness.attributes 中set属性限制导致,流程执行到checkScaleInCvmCluster后,执行如下命令:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
PUT _cluster/settings
{
  "persistent": {
    "cluster.routing.allocation.awareness.attributes": "ip"
  },
  "transient": {
    "cluster.routing.allocation.awareness.attributes": "ip"
  }
}

执行完上述命令后,卡住的分片随后会自动迁移,并且老的可用区节点自动下线, "cluster.routing.allocation.awareness.attributes": "ip"会自动还原为 "cluster.routing.allocation.awareness.attributes" : "set,ip"
