Head First 设计模式之命令模式,各司其职提高效率

作者头像
用户4361942
发布2019-05-24 17:03:10
4340
发布2019-05-24 17:03:10
举报
文章被收录于专栏:java程序员思维

命令模式

命令模式(Command Pattern)是一种数据驱动的设计模式,它属于行为型模式。请求以命令的形式包裹在对象中,并传给调用对象。调用对象寻找可以处理该命令的合适的对象,并把该命令传给相应的对象,该对象执行命令。

命令模式解决的问题

命令模式是将行为请求者和行为实现者解耦合的方式。对命令进行封装,将命令和执行命令分隔开。请求的一方发出命令,要求执行某些操作,接受一方收到命令,执行这些操作的真正实现。

命令模式模式角色

客户端(Client)角色:创建一个具体命令(ConcreteCommand)对象并确定其接收者。

命令(Command)角色:声明了一个给所有具体命令类的抽象接口。

具体命令(ConcreteCommand)角色:定义一个接收者和行为之间的弱耦合;实现execute()方法,负责调用接收者的相应操作。execute()方法通常叫做执行方法。

请求者(Invoker)角色:负责调用命令对象执行请求,相关的方法叫做行动方法。

接收者(Receiver)角色:负责具体实施和执行一个请求。任何一个类都可以成为接收者,实施和执行请求的方法叫做行动方法。

使用场景

Transactional behavior(原子事务行为) 借助command模式,可以简单地实现一个具有原子事务的行为。当一个事务失败时,往往需要回退到执 行前的状态,可以借助command对象保存这种状态,简单地处理回退操作。

Thread pools(线程池) 通常一个典型的线程池实现类可能有一个名为addTask()的public方法,用来添加一项工作任务到任务 队列中。该任务队列中的所有任务可以用command对象来封装,通常这些command对象会实现一个通用的接口比如java.lang.Runnable。

命令模式和策略模式的区别

命令模式是含有不同的命令:做不同的事情;隐藏接收者执行细节。策略模式含有不同的算法,做相同的事情;两者关键区别在于是否含有接收者。命令模式含有,策略模式不含有。

代码实现

代码语言:javascript
复制
/**
 * 命令(Command)角色
 */
public interface Command {
 public void execute();
}
代码语言:javascript
复制
/**
 * 具体命令
 */
public class LightOffCommand implements Command{
 private Receiver receiver;
 public LightOffCommand(Receiver receiver) {
 this.receiver = receiver;
 }
 public void execute() {
 receiver.turnOFF();
 }
}
代码语言:javascript
复制
/**
 *
 * 具体命令
 */
public class LightOnCommand implements Command{
 private Receiver receiver;
 public LightOnCommand(Receiver receiver) {
 this.receiver = receiver;
 }
 public void execute() {
 receiver.turnON();
 }
}
代码语言:javascript
复制
/**
 *
 * 命令接收者:执行命令
 */
public class Receiver {
 public void turnON() {
 System.out.println("执行开灯操作...");
 }
 public void turnOFF() {
 System.out.println("执行关灯操作...");
 }
}
代码语言:javascript
复制
/**
 * Created by zengjianlu on 2018/2/24.
 *
 * 命令调用者:负责调用
 */
public class Invoker {
 public void execute(Command command){
 command.execute();
 }
}
代码语言:javascript
复制
/**
 * 测试类
 */
public class Test {
 public static void main(String[] args) {
 Receiver receiver = new Receiver();
 Invoker invoker = new Invoker();
 Command turnOnLight = new LightOnCommand(receiver);
 Command turnOffLight = new LightOffCommand(receiver);
 invoker.execute(turnOnLight);
 invoker.execute(turnOffLight);
 }
}

运行结果:

以上代码存在缺陷,如果增加一个新的命令需要修改Receiver类,违背了开闭原则,可以结合策略模式,将Receiver定义成一个接口,不同的命令使用不同的具体的Receiver,这样就能满足开闭原则。

JDK中的命令模式

代码语言:javascript
复制
public interface Runnable {
 /**
 * When an object implementing interface <code>Runnable</code> is used
 * to create a thread, starting the thread causes the object's
 * <code>run</code> method to be called in that separately executing
 * thread.
 * <p>
 * The general contract of the method <code>run</code> is that it may
 * take any action whatsoever.
 *
 * @see java.lang.Thread#run()
 */
 public abstract void run();
}

Runable是一个典型命令模式,Runnable担当命令的角色,Thread充当的是调用者,start方法就是其执行方法

代码语言:javascript
复制
public synchronized void start() {
 /**
 * This method is not invoked for the main method thread or "system"
 * group threads created/set up by the VM. Any new functionality added
 * to this method in the future may have to also be added to the VM.
 *
 * A zero status value corresponds to state "NEW".
 */
 if (threadStatus != 0)
 throw new IllegalThreadStateException();
 /* Notify the group that this thread is about to be started
 * so that it can be added to the group's list of threads
 * and the group's unstarted count can be decremented. */
 group.add(this);
 boolean started = false;
 try {
 start0();
 started = true;
 } finally {
 try {
 if (!started) {
 group.threadStartFailed(this);
 }
 } catch (Throwable ignore) {
 /* do nothing. If start0 threw a Throwable then
 it will be passed up the call stack */
 }
 }
}

会调用一个native方法start0(),调用系统方法,开启一个线程。而接收者是对程序员开放的,可以自己定义接收者。

代码语言:javascript
复制
/**
 * jdk Runnable 命令模式
 *
 */
public class TurnOffThread implements Runnable{
 private Receiver receiver;
 public TurnOffThread(Receiver receiver) {
 this.receiver = receiver;
 }
 public void run() {
 receiver.turnOFF();
 }
}
代码语言:javascript
复制
/**
 * 测试类
 */
public class TurnOffThreadTest {
 public static void main(String[] args) {
 Receiver receiver = new Receiver();
 TurnOffThread turnOffThread = new TurnOffThread(receiver);
 Thread thread = new Thread(turnOffThread);
 thread.start();
 }
}

优缺点

优点:降低系统的耦合度。新的命令可以很容易地加入到系统中。可以比较容易地设计一个命令队列和宏命令。可以方便地实现对请求的Undo和Redo。

缺点:使用命令模式可能会导致某些系统有过多的具体命令类。因为针对每一个命令都需要设计一个具体命令类,因此某些系统可能需要大量具体命令类,这将影响命令模式的使用。

生活中的命令模式

餐厅点菜场景,客人订单发起者、厨师订单执行者,客人不会直接对厨师直接下单,而是通过服务员这个订单接收者,客人和厨师解耦。如果不这样做会怎样?厨师先去大厅,接受用户的订单,然后厨师拿着订单去做菜,做完菜再把菜端给客人,这个时间段其他用户需要等待,如果采用命令行模式,服务员负责给用户点单,厨师只要负责做好一件事就是做菜,分工明确,客人不需要等待,有点像流水线,提高了用户体验和工作效率。

我的启发

效率是企业的一个重要指标,人效、组织效率、资产效率、战略效率、创新效率,命令模式提供了一种高内聚、低耦合的方式,让不同角色,各司其职,专注自己本职工作,很好的提高用户体验和效率。
